Quick Details
-
Roll Ratio(Front/Back):
-
1:1.27
-
Cooling Mode:
-
water
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HUICAI
-
Voltage:
-
220V 380V 450V
-
Dimension(L*W*H):
-
6120x2300x2000
-
Power (kW):
-
75
-
Weight (KG):
-
11400 KG
-
Type:
-
Open Mixing Mill
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Category:
-
Rubber mixing mill
-
Roller:
-
chilled cast iron
-
Motor:
-
Chinese famous brand
-
Reducer:
-
Hard-tooth surface gear reducer
-
Rolling bearing:
-
Dual-listed rolling bearings
-
Roll gap adjustment:
-
electric automatic
-
Blocking:
-
optional
-
Stock blender:
-
optional
Quick Details
-
Diameter of Roll(mm):
-
450 mm
-
Rotation Speed of Front Roll(rpm):
-
21 - 22 rpm
-
Length of Roll(mm):
-
1200 mm
-
Roll Ratio(Front/Back):
-
1:1.27
-
Cooling Mode:
-
water
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HUICAI
-
Voltage:
-
220V 380V 450V
-
Dimension(L*W*H):
-
6120x2300x2000
-
Power (kW):
-
75
-
Weight (KG):
-
11400 KG
-
Type:
-
Open Mixing Mill
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Category:
-
Rubber mixing mill
-
Roller:
-
chilled cast iron
-
Motor:
-
Chinese famous brand
-
Reducer:
-
Hard-tooth surface gear reducer
-
Rolling bearing:
-
Dual-listed rolling bearings
-
Roll gap adjustment:
-
electric automatic
-
Blocking:
-
optional
-
Stock blender:
-
optional
Product Description
| Type | XK-160 | XK-250 | XK-300 | XK-360 | XK-400 | XK-450 | XK-550 | XK-560 | XK-610 | |||
| 1.Roll diameter (mm) | 160 | 250 | 300 | 360 | 400 | 450 | 550 | 560-510 | 610 | |||
| 2.Roll working length (mm) | 320 | 620 | 700 | 900 | 1000 | 1200 | 1530 | 1530 | 1930 | |||
| 3.Front roll linear speed (m/min) | 9 | 16.3 | 16.3 | 16.7 | 18.65 | 21.8 | 28 | 26.4 | 30.5 | |||
| 4.Speed ratio of rolls | 1:1.35 | 1:1.7 | 1:1.25 | 1:1.25 | 1:1.27 | 1:1.27 | 1:1.2 | 1:1.2 | 1:1.1 | |||
| 5.Max roll space (mm) | 0.1-4.5 | 0.1-8 | 0.1-4.5 | 0.1-10 | 0.1-10 | 0.1-12 | 0.1-16 | 0.1-15 | 0.1-15 | |||
| 6.Compound feeding capacity (kg) | 1-2 | 10-15 | 5-15 | 15-20 | 18-35 | 50 | 50-65 | 50-65 | 140 | |||
| 7.Motor power (kw) | 5.5 | 18.5 | 30 | 30 | 45 | 55 | 110 | 90 | 160 | |||
| 8.Overal size (mm) | 1120 | 3300 | 4020 | 4200 | 4400 | 5200 | 6300 | 6120 | 6570 | |||
| 920 | 1300 | 1500 | 1780 | 1850 | 2000 | 2300 | 2300 | 2900 | ||||
| 1350 | 1200 | 1500 | 1700 | 1760 | 1830 | 1900 | 2000 | 2100 | ||||
- The speed reducer is the hard-tooth surface gear speed reducer of Class 6 precision, which has long service life and low noise.
- Chilled alloy cast iron roll is abrasion resistant with long service life.
- Dual-listed rolling bearings, which reduces energy consumption by 30%.
- Roll gap adjustment : electric automatic
- Motor: Frequency control of motor speed
