Quick Details
-
Graphic Format Supported:
-
AI, Dst, Dwg, DXF, DXP, PLT
-
Cooling Mode:
-
Air Cooling
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SPEEDY LASER
-
Dimension(L*W*H):
-
890x430x860mm
-
Weight (KG):
-
60 KG
-
Core Components:
-
laser source
-
After-sales Service Provided:
-
Overseas service center available, Online support
-
Laser power:
-
50W
-
Laser Source:
-
Raycus / JPT / MAX
-
Type:
-
Deep Engraving Machine
-
Function:
-
marking logo, serial number, bar code
-
Laser life:
-
100,000 hours
-
HS code:
-
8456110090
-
Software:
-
EZcad
-
Warrenty:
-
2 years
-
Marking depth:
-
0.01-0.5mm
Quick Details
-
Engraving Area:
-
110*110mm
-
Laser Type:
-
Fiber Laser
-
Engraving Speed:
-
0-7000mm/s
-
Graphic Format Supported:
-
AI, Dst, Dwg, DXF, DXP, PLT
-
Cooling Mode:
-
Air Cooling
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SPEEDY LASER
-
Dimension(L*W*H):
-
890x430x860mm
-
Weight (KG):
-
60 KG
-
Core Components:
-
laser source
-
After-sales Service Provided:
-
Overseas service center available, Online support
-
Laser power:
-
50W
-
Laser Source:
-
Raycus / JPT / MAX
-
Type:
-
Deep Engraving Machine
-
Function:
-
marking logo, serial number, bar code
-
Laser life:
-
100,000 hours
-
HS code:
-
8456110090
-
Software:
-
EZcad
-
Warrenty:
-
2 years
-
Marking depth:
-
0.01-0.5mm
| Technical Parameter | |||
| Model NO. | SL-FM 20W | SL-F M 30W | SL-F M 50W |
| Laser power | 20W | 30W | 5 0W |
| Laser wavelength | 1064nm | ||
| Laser type | Raycus / JPT / MAX fiber laser | ||
| Beam diameter | 7mm±1 | ||
| Repeat frequency | 20KHz-60KHz | 30KHz-60KHz | 50KHz-100KHz |
| Pulse width | 131ns | 131ns | 135ns |
| Repeated accuracy | +/-0.01mm | ||
| Marking depth | 0.01-0.5mm | ||
| Marking area | 110×110mm/175×175mm/200×200mm | ||
| Power consumption | 500W | 600W | 800W |
| Operating voltage | 110V- 240V/50-60 Hz/15A | ||
| Carve speed | 2000mm character/s | ||
| Cooling | Air Cooling | ||
| Packing size | 88*44*80 cm (L*W*H) | ||
| Gross weight | 60 KG | ||
| Package | Standard export wooden case | ||
| 24/7 service is available to each customer. And if any technical questions or problems, our engineers will help you and give you solutions on the phone or by face-to-face communication online. |
| 2 years warranty is provided. (The detailed reference will be written into the final contract.) |
| Professional staff for installation and training. |
| Spare parts are supplying on time or doing some inventory if promising certain sales volume. |
| Faster delivery, we will support our sole agent to do the stock if good sales, then more convenient and helpful. |
| If the sales are good, we will arrange some famous exhibition fairs in the local or surroundings, and give our full support to our agents at the fair. We will provide our sample machines, catalog, DVD, manuals, etc. All native customers belong to our local agent, which is our basic rule. And we promise the final delivery is the same as displayed prototype. |
