Quick Details
-
Ejector Stroke(mm):
-
350 mm
-
Ejector Force(kN):
-
45 kN
-
Theoretical Shot Volume(cm³):
-
796 cm³
-
Injection Rate (g/s):
-
298 g/s
-
Machine Type:
-
Preform Injection
-
Injection Weight (g):
-
740 g
-
Screw Speed (rpm):
-
0 - 180 rpm
-
Screw diameter (mm):
-
65 mm
-
Distance between Tie Bars:
-
910x450 mm
-
Weight (KG):
-
12500 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
350 mm
-
Model Number:
-
ST-200T-2S
-
Brand Name:
-
ST
-
Power (kW):
-
37.5 kW
-
Applicable Industries:
-
Manufacturing Plant, Home Use, Printing Shops, Oth
-
Core Components:
-
Bearing, Motor, Pump, Gear, PLC, Other, Pressure v
-
Max.Opening:
-
700(800)mm
-
(H'V) Distance Between Tie Bars:
-
910*450mm
-
(L*W)Max.Mould Size:
-
750*620mm
-
Ejector Distance:
-
150mm
-
Ejector Force:
-
45(4.6)KN(tf)
-
System Pressure:
-
13.7(140)Mpa(kgf/cm2)
-
OiTank Capacity:
-
920L
-
Motor Power:
-
37.5(50)KW(HP)
-
Machine Dimensions:
-
2.9*2.1*4.4m
-
Machine Weight:
-
12500 KG
Quick Details
-
Plasticizing Capacity(g/s):
-
740
-
Mold Height(mm):
-
350 - 450 mm
-
Ejector Number:
-
Other
-
Ejector Stroke(mm):
-
350 mm
-
Ejector Force(kN):
-
45 kN
-
Theoretical Shot Volume(cm³):
-
796 cm³
-
Injection Rate (g/s):
-
298 g/s
-
Machine Type:
-
Preform Injection
-
Injection Weight (g):
-
740 g
-
Screw Speed (rpm):
-
0 - 180 rpm
-
Screw diameter (mm):
-
65 mm
-
Distance between Tie Bars:
-
910x450 mm
-
Weight (KG):
-
12500 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
350 mm
-
Model Number:
-
ST-200T-2S
-
Brand Name:
-
ST
-
Power (kW):
-
37.5 kW
-
Applicable Industries:
-
Manufacturing Plant, Home Use, Printing Shops, Oth
-
Core Components:
-
Bearing, Motor, Pump, Gear, PLC, Other, Pressure v
-
Max.Opening:
-
700(800)mm
-
(H'V) Distance Between Tie Bars:
-
910*450mm
-
(L*W)Max.Mould Size:
-
750*620mm
-
Ejector Distance:
-
150mm
-
Ejector Force:
-
45(4.6)KN(tf)
-
System Pressure:
-
13.7(140)Mpa(kgf/cm2)
-
OiTank Capacity:
-
920L
-
Motor Power:
-
37.5(50)KW(HP)
-
Machine Dimensions:
-
2.9*2.1*4.4m
-
Machine Weight:
-
12500 KG
Product Description
Machine Details
Machine Parameter
|
Model
|
Model
|
ST-200T-2S
|
|
|
|||
|
PARAMETER
|
UNIT
|
|
|
|
|||
|
Screw Diameter
|
mm
|
55
|
60
|
65
|
|||
|
Theoryof injection quantity
|
cm³
|
570
|
678
|
796
|
|||
|
lnjection quality
|
g/oz
|
530/18.6
|
630/22.2
|
740/26.1
|
|||
|
The maximuminjection pressure
|
Mpa(Kgf/cm2)
|
235(2406)
|
198(2202)
|
168(1722)
|
|||
|
injectionrate
|
cm³/s
|
214
|
254
|
298
|
|||
|
Injection speed
|
mm/s
|
90
|
|
|
|||
|
Rate of increase
|
mm/s
|
225(120T)/148(150T)
|
|
|
|||
|
Screw Rotation Speed
|
rpm
|
0-180
|
|
|
|||
|
Nozzle highlight the templale size
|
mm
|
>=45
|
|
|
|||
|
Clamping Force
|
KN(tf)
|
1960(200)
|
|
|
|||
|
Clamping Stroke
|
mm
|
350
|
|
|
|||
|
Min, Mold Thickness
|
mm
|
350(450)
|
|
|
|||
|
Max.Opening
|
mm
|
700(800)
|
|
|
|||
|
(H*V}Distance Between Tie Bars
|
mm
|
910*450
|
|
|
|||
|
(L*W)Max.Mould Size
|
mm
|
750*620
|
|
|
|||
|
Ejector Distance
|
mm
|
150
|
|
|
|||
|
Ejector Force
|
KN(tf)
|
45(4.6)
|
|
|
|||
|
System Pressure
|
Mpa(kgf/cm2)
|
13.7(140)
|
|
|
|||
|
OilTank Capacity
|
L
|
920
|
|
|
|||
|
Motor Powwer
|
KW(HP)
|
37.5(50)
|
|
|
|||
|
Machine Dimensions
|
M
|
2.9*2.1*4.4
|
|
|
|||
|
Machine Weight
|
tf
|
12.5
|
|
|
|||
