Quick Details
-
Place of Origin:
-
Chongqing, China
-
Brand Name:
-
TJ
-
Dimension(L*W*H):
-
520*411*460
-
Weight:
-
37.7
-
Rated power/speed:
-
11-3600
-
Model:
-
TJ 500
-
Engine type:
-
2 cylinder, 4 Stroke,Air Coolling OHV
-
Bore x Stroke (mm):
-
94*72
-
Horse power(HP):
-
19.5
-
Compression:
-
8.5:1
-
Starting method:
-
E-start
-
Rated output(Kw-r/mim):
-
11-3600
-
Max torque(N.m-r/min):
-
31-2500
-
Loading Qty (20GP/40HQ):
-
160/420
Quick Details
-
Displacement:
-
500 CC, 500cc
-
Emission Standard:
-
CE or Euro 5
-
Power:
-
19.5 HP
-
Place of Origin:
-
Chongqing, China
-
Brand Name:
-
TJ
-
Dimension(L*W*H):
-
520*411*460
-
Weight:
-
37.7
-
Rated power/speed:
-
11-3600
-
Model:
-
TJ 500
-
Engine type:
-
2 cylinder, 4 Stroke,Air Coolling OHV
-
Bore x Stroke (mm):
-
94*72
-
Horse power(HP):
-
19.5
-
Compression:
-
8.5:1
-
Starting method:
-
E-start
-
Rated output(Kw-r/mim):
-
11-3600
-
Max torque(N.m-r/min):
-
31-2500
-
Loading Qty (20GP/40HQ):
-
160/420
Products Description
Specification
|
Model
|
TJ500
|
|
|
Engine type
|
2 cylinder, 4 Stroke, Air-Coolling OHV
|
|
|
Bore x Stroke (mm)
|
94*72
|
|
|
Displacement
|
500cc
|
|
|
Horse power(HP)
|
19.5
|
|
|
Compression
|
8.5:1
|
|
|
Rated output(Kw-r/mim)
|
11-3600
|
|
|
Max torque(N.m-r/min)
|
31-2500
|
|
|
Min.fuel consumption(g/Kw.h)
|
≤374
|
|
|
Dimensiones
|
545*450*520
|
|
|
Net weight (kgs)
|
37.7
|
|
|
Loading Qty (20GP/40HQ)
|
160/420
|
|
