Quick Details
-
Dimension(L*W*H):
-
4*3*2.4m
-
Year:
-
2022
-
Power (kW):
-
268 kW
-
Weight (KG):
-
30000 KG
-
Applicable Industries:
-
Tire Recycling
-
End product:
-
Rubber Particle/Rubber Powder
-
Capacity:
-
500-10000kg/h
-
Marketing Type:
-
Ordinary Product
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
YUXI
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
4*3*2.4m
-
Year:
-
2022
-
Power (kW):
-
268 kW
-
Weight (KG):
-
30000 KG
-
Applicable Industries:
-
Tire Recycling
-
End product:
-
Rubber Particle/Rubber Powder
-
Capacity:
-
500-10000kg/h
-
Marketing Type:
-
Ordinary Product
Product Description
Our
waste tire recycling production line
made of different type heavy equipment, it can realize separate car tire, truck tire and engineering tire fully automatically.
Based on client demand, make rubber material
pelleting and grinding
, this series production line
working under normal temperature, no need any chemical additive, won't cause secondary environment pollution. choosing the suitable model machine, we make the proposal closed to real production demand, let user control cost and get ultimate pay back by waste tire recycling machine.
|
Technical Parameters
|
|
|
|
Capacity
|
500-10000kg/h
|
|
|
Scope of application
|
Diameter of the tire: 400-3000mm
|
|
|
Output size
|
5-100mesh, can be Customized
|
|
|
Complete separation
|
The rubber crumbs, steel and fibre can be separated automatically.
Adopt PLC control system, it is simple and easy to control and maintain. For example, it is only need 4-6persons to operate a tire recycling(granule) production line with 3000kg/h capacity. Low energy consumption. the installed power of tire recycling production (granule) line with capacity 3000kg/h is about 800kw. |
|
|
Equipment required area
|
About 680square meter, 7m height
|
|
|
Characteristic of blade
|
Long service life, high utilization, multiple maintenance
|
|
Waste rubber powder production line consists of tire broken machine host and auxiliary machine two parts.Auxiliary equipment:Hook Wire Drawing Machine,Tire Cutter Machine(Optional according to tire size),Conveyor,Magnetic Separator Machine,and other components.
Final products
Application Scopes
What Is The Application of Used Tires?
Recycling of used tires after smashing has become a new industry hotspot and development trend. The following product applications are for your reference
1.8-20 mesh
, mainly used for runways, road cushions, sports pavements, etc.
2.30-40 mesh
, mainly used for reclaimed rubber, paving, producing rubber sheets
3.40-60 mesh
, mainly used for rubber rubber filling, plastic modification.
4.60-80 mesh
, mainly used in automobile tires, rubber products, building materials.
Detailed Images
<1>Fully automatic wire drawing machine
Remove tire steel wheel.
Separate the rubber and steel wire and process it into rubber particles (10mm-20mm)
<4>Magnetic separator
Sorting steel wire from rubber wire mixture
<5>Grinder Mill
The particles are ground to a powder (30 mesh to 100 mesh)
To remove dust and textiles created during the pr-shredding,secondary size reduction,granulation,classifying and textile separation stages.
Working Process:
Customer Site
Recently Our 81000kg/h tyre recycling plant install in Europe
