Quick Details
-
Working area:
-
600mm x900mm
-
Control system:
-
Mach3
-
Travel on z-axis:
-
120mm
-
Working speed:
-
5m/min
-
Working accuracy:
-
0.05mm
-
Weight:
-
450kgs
-
Power(W):
-
2.2KW
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Spindle:
-
2.2kw Water Cooling Spindle
-
Spindle speed:
-
0-24000RPM
-
Working area:
-
600mm x900mm
-
Control system:
-
Mach3
-
Travel on z-axis:
-
120mm
-
Working speed:
-
5m/min
-
Working accuracy:
-
0.05mm
-
Weight:
-
450kgs
-
Power(W):
-
2.2KW
- Heavy duty steel structure provides high stability and accuracy
- 600mm x 900mm working area
- Aluminum T-slot table with PVC pads securely hold down any workpieces
- 2.2kw water cooled spindle for long hours machining
- Ease-to-use MACH 3 operation system
- High quality square linear guide-ways
- Comes with 3-axis ball screws and stepper motors as standard
- 120mm travel on Z-axis (250mm travel is available)
- Optional servo control is available
- Working area: 600mm x900mm
- Travel on Z-axis: 120mm
- Whole structure: steel structure
- Table type: Aluminum T-slot table with PVC pads
- Guide rail: Square linear guide rails
- Driving method: Ball-screws on X/Y/Z
- Spindle: 2.2kw water cooling spindle
- Spindle speed: 24000rpm
- Collet size: ER20
- Control system: Mach 3
- Working accuracy: 0.05mm
- Repetitive positioning accuracy: 0.01mm
- Rapid travel speed: 10m/min
- Max. working speed: 10m/min
- Working voltage: 220v. 50hz, single phase
- Environment temperature: 0 – 45 ℃
- Environment humidity : 30% - 75% No coagulate water
- Approx. machine weight: 450kgs
- Machine dimensions: 1500mm x1000mm x1900mm
