Quick Details
-
Brand Name:
-
HIRP
-
Model Number:
-
RP5C-400
-
Rated Current:
-
400A
-
Certificate:
-
CE,CB
-
Standard Control voltage:
-
220V/230V
-
Frequency:
-
50/60Hz
-
Non-Standard Control voltage:
-
110V customized
-
Function:
-
Give auto Start generator siginal
-
Transfer Time:
-
less than 4 seconds
-
Working State:
-
3 position:I-O-II
-
Max. Voltage:
-
400V
-
Warranty:
-
1.5 years
-
Certification:
-
CE, CB, ROHS
Quick Details
-
Type:
-
PC
-
Number of Pole:
-
4
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HIRP
-
Model Number:
-
RP5C-400
-
Rated Current:
-
400A
-
Certificate:
-
CE,CB
-
Standard Control voltage:
-
220V/230V
-
Frequency:
-
50/60Hz
-
Non-Standard Control voltage:
-
110V customized
-
Function:
-
Give auto Start generator siginal
-
Transfer Time:
-
less than 4 seconds
-
Working State:
-
3 position:I-O-II
-
Max. Voltage:
-
400V
-
Warranty:
-
1.5 years
-
Certification:
-
CE, CB, ROHS
Product Description
| Conventional Heating Current | 100A | 125A | 160A | 250A | 400A | 630A | 800A | 1000A | 1250A | 1600A | 2000A | 2500A | 3200A | |
| Rated Insulation Voltage Ui | 690V | 800V | ||||||||||||
| Rated Impaction Withstand Voltage Uimp | 8kV | 12kV | ||||||||||||
| Rated Working Voltage Ue | AC440V | |||||||||||||
| Rated Working Current Ie | AC-32B | 100 | 125 | 160 | 250 | 400 | 630 | 800 | 1000 | 1250 | 1600 | 2000 | 2500 | 3200 |
| Rated Making Capacity | 10kA | 17kA | 25.2kA | 34kA | ||||||||||
| Rated Limiting Short-Circuit Current | 50kA | 20kA | 50kA | |||||||||||
| Rated Short Time Withstand Current | 7kA | 10kA | 12.6kA | 20kA | ||||||||||
| Change-Over Time | 1's | 2's | 3's | |||||||||||
| Voltage of Control Power Supply | AC220V | |||||||||||||
| Energy Consumption of the Motor | Start | 250W | 300W | 325W | 355W | 400W | 440W | 600W | ||||||
| Normal | 40W | 55W | 62W | 74W | 90W | 98W | 120W | |||||||
