Quick Details
-
Injection Rate (g/s):
-
55 g/s
-
Injection Weight (g):
-
89 g
-
Screw diameter (mm):
-
32 mm
-
Distance between Tie Bars:
-
260mm
-
Weight (KG):
-
2000
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
200 mm
-
Model Number:
-
FT-400DS
-
Brand Name:
-
FOMTEC
-
Power (kW):
-
7.5 kW
-
Plastic Type:
-
Thermoplastic
-
Automatic:
-
Yes
-
molding machine:
-
Sliding Table molding machine
-
Table plastic Verticla machine:
-
Injection Molding Machine
-
Opening Stroke:
-
200mm
-
Injection Rate:
-
42~70cm3/sec
-
Injection Weight:
-
68~113g
-
Power:
-
5.5kw
-
After-sales Service Provided:
-
Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support
-
After Warranty Service:
-
Online support, Spare parts
-
Local Service Location:
-
None
-
Certification:
-
CE,ISO ,,TUV
Quick Details
-
Ejector Stroke(mm):
-
55 mm
-
Ejector Force(kN):
-
1.5 kN
-
Theoretical Shot Volume(cm³):
-
97 cm³
-
Injection Rate (g/s):
-
55 g/s
-
Injection Weight (g):
-
89 g
-
Screw diameter (mm):
-
32 mm
-
Distance between Tie Bars:
-
260mm
-
Weight (KG):
-
2000
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
200 mm
-
Model Number:
-
FT-400DS
-
Brand Name:
-
FOMTEC
-
Power (kW):
-
7.5 kW
-
Plastic Type:
-
Thermoplastic
-
Automatic:
-
Yes
-
molding machine:
-
Sliding Table molding machine
-
Table plastic Verticla machine:
-
Injection Molding Machine
-
Opening Stroke:
-
200mm
-
Injection Rate:
-
42~70cm3/sec
-
Injection Weight:
-
68~113g
-
Power:
-
5.5kw
-
After-sales Service Provided:
-
Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support
-
After Warranty Service:
-
Online support, Spare parts
-
Local Service Location:
-
None
-
Certification:
-
CE,ISO ,,TUV
| INJECTION UNIT | Screw Diameter | mm | φ28 | φ32 | φ36 |
| Maximum Injection Pressure | Bar | 2000 | 1531 | 1210 | |
| Theoretical Shot Volume | cm 3 | 74 | 97 | 122 | |
| Maximum Shot Weight(PS) | g | 68 | 89 | 113 | |
| oz | 2.4 | 3.1 | 4.0 | ||
| Injection Rate | cm 3 /sec | 42 | 55 | 70 | |
| CLAMPING UNIT | Clamping Force | kN | 400 | ||
| Top Platen Size | mm | 550×395 | |||
| Slide Table Size | mm | 390×820 | |||
| Slide Stroke | mm | 420 | |||
| Mold Size | mm | 410×255 | |||
| Minimum Mold Thickness | mm | 150/250 | |||
| Opening Stroke | mm | 200 | |||
| Open Daylight | mm | 350/450 | |||
| Ejector Force | kN | 15 | |||
| Ejector Stroke | mm | 55 | |||
| OTHERS | Hydraulic System Pressure | Bar | 140 | ||
| Oil Tank Volume | L | 210 | |||
| Electric Power | hp(kW) | 7.5(5.5) | |||
| Barrel Heating Power | kW | 3.6 | |||
| Total Wattage | kW | 9.1 | |||
| Machine Dimensions(approx.) | m | 1.8×1.5×2.5 | |||
| Machine Weight(approx.) | kg | 2000 | |||
