Quick Details
-
Dimension(L*W*H):
-
2600*1450*1600mm
-
Weight:
-
3500
-
Power (kW):
-
15
-
advantage1:
-
no oil leakage
-
advantage2:
-
no pressure leakage
-
control system:
-
PLC
-
Marketing Type:
-
Ordinary Product
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
CGY
-
Voltage:
-
customer demand
-
Dimension(L*W*H):
-
2600*1450*1600mm
-
Weight:
-
3500
-
Power (kW):
-
15
-
advantage1:
-
no oil leakage
-
advantage2:
-
no pressure leakage
-
control system:
-
PLC
-
Marketing Type:
-
Ordinary Product
Specifications
|
Type
|
CJN-120
|
CJN-160
|
CJN-200
|
|
Applicable inner tube
|
bicycle
|
Bicycle/motorcycle
|
Bicycle/motorcycle
|
|
Applicable rubber
|
Natural/butyl rubber
|
Natural/butyl rubber
|
Natural/butyl rubber
|
|
Electro-cutting mode
|
vertical
|
Vertical
|
vertical
|
|
Pressed tyre hose width
|
30-200mm
|
30-200mm
|
30-200mm
|
|
Length of inner tube(circular)
|
380mm
|
380mm
|
380mm
|
|
Max. jointing force
|
1600N
|
1600N
|
1600N
|
|
Max. clamping force
|
2500N
|
2500N
|
2500N
|
|
Jointing intension
|
0.8-1.0N/sqmm
|
0.8-1.0N/sqmm
|
0.8-1.0N/sqmm
|
|
Working air pressure
|
0.4-0.6MPa
|
0.4-0.6MPa
|
0.4-0.6MPa
|
|
Tube hose thickness(double-layers)
|
2-6mm
|
2-6mm
|
2-6mm
|
|
Working cycle
|
15-25sec
|
15-25sec
|
15-25sec
|
|
Electro cutter temp.
|
0-500
0
C
|
0-500
0
C
|
0-500
0
C
|
|
Tube jointing number
|
1-4 pcs
|
Bicycle: 1-4pcs
Motorcycle: 1-2pcs
|
Bicycle:1-4pcs
Motorcycle: 1-2pcs
|
