Quick Details
-
Model Number:
-
OTM-RE30
-
Output Frequency:
-
50/60Hz
-
Driver Mode:
-
round shape led driver constant voltage
-
Input voltage:
-
90-265v
-
Ouput power:
-
30w
-
Efficiency:
-
86%
-
PF:
-
0.95
-
Size:
-
65*25mm
-
Protection:
-
Open-circuit,Short-circuit,Over-voltage,Over-current,Over-temp
-
IP Grade:
-
IP20
-
Warranty:
-
3 Years
Quick Details
-
Warranty(Year):
-
5-Year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OTM
-
Model Number:
-
OTM-RE30
-
Output Frequency:
-
50/60Hz
-
Driver Mode:
-
round shape led driver constant voltage
-
Input voltage:
-
90-265v
-
Ouput power:
-
30w
-
Efficiency:
-
86%
-
PF:
-
0.95
-
Size:
-
65*25mm
-
Protection:
-
Open-circuit,Short-circuit,Over-voltage,Over-current,Over-temp
-
IP Grade:
-
IP20
-
Warranty:
-
3 Years
Specifications
| OTM-RE12 | OTM-RE30 | |
| DC output voltage | 12V | 24V |
| Output voltage error | ±1% | ±1% |
| Rated output current | 2.5A | 1.25A |
| Output current range | 0-2.5A | 0-1.25A |
| Wave and noise | 100mVp-p | 100mVp-p |
| Inlet stability | ±0.5% | ±0.5% |
| Load stability | ±0.5% | ±0.5% |
| DC output power | 30W | 30W |
| Efficiency | 86% | 86% |
| AC input voltage range | 90-265V | |
| Input current | 0.5A/115V 0.25A/230V | |
| AC impulse current | Cold-start current 13A/115V 26A/230V | |
| Leakage current | <0.5mA/240VAC | |
| Over load protection | 105%~150% rated output power | |
| Protection:Hiccup mode | ||
| Over voltage protection | 13~16V | 28~32V |
| Protection:Shut down output voltage | ||
| short circuit protection | Protection:Hiccup mode | |
| Temperature coefficient | ±0.03%(050) | |
| Setup rise hold up time | 200ms,100ms,30ms | |
| Vibration | 10~500Hz,2G 10min./1cycle,Period for 60min,Each axes | |
| Withstand voltage | I/P-O/P:2.5KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | |
| Isolation resistance | I/P-O/P:100M Ohms / 500VDC / 25 / 65% RH | |
| Working temperature and humidity | -10~+60 °C , 20~90%RH | |
| Store temperature and humidity | -20~+85 °C , 10~95%RH | |
| Warranty | 3-5years | |
