Hot Sale Rubber Strainer Process Reclaimed Rubber for Electricity Cable
Hot Sale Rubber Strainer Process Reclaimed Rubber for Electricity Cable
Hot Sale Rubber Strainer Process Reclaimed Rubber for Electricity Cable
Hot Sale Rubber Strainer Process Reclaimed Rubber for Electricity Cable
Hot Sale Rubber Strainer Process Reclaimed Rubber for Electricity Cable
Hot Sale Rubber Strainer Process Reclaimed Rubber for Electricity Cable
Hot Sale Rubber Strainer Process Reclaimed Rubber for Electricity Cable
Hot Sale Rubber Strainer Process Reclaimed Rubber for Electricity Cable

Hot Sale Rubber Strainer Process Reclaimed Rubber for Electricity Cable

FOB Reference Price: Get Latest Price
≥1 Sets
US $10500
≥3 Sets
US $10000
Free Inquiry
Customized Request
Contact us For product pricing, customization, or other inquiries:
Contact Us
  • Product Details
  • {{item.text}}

Quick Details

Dimension(L*W*H):
4350*1850*1785
Year:
2024
Power (kW):
55 kW
Weight (KG):
3000 KG
Model:
SXJL-200
Roller Diameter:
200 mm
L:D:
4.5:1
Screw Rotational Speed:
45
Steam Pressure:
0.6-0.8 Mpa
Cooling Water Pressure:
0.2 Mpa

Quick Details

Place of Origin:
Shandong, China
Brand Name:
SFC
Voltage:
380V
Dimension(L*W*H):
4350*1850*1785
Year:
2024
Power (kW):
55 kW
Weight (KG):
3000 KG
Model:
SXJL-200
Roller Diameter:
200 mm
L:D:
4.5:1
Screw Rotational Speed:
45
Steam Pressure:
0.6-0.8 Mpa
Cooling Water Pressure:
0.2 Mpa
Products Description
Equipment Application
It is widely used in rubber products such as cable industry, renewable rubber industry, inner tire industry and rubber pipe industry!
Usage:
About rubber materials after mixing by rubber kneader, without the old process through mixing mill output strip and feeding old strainer, this new type strainer can directly feed clumps of block to double-pull feeding mechanism, using screw pushing,conveying, the mixed gum or removing the impurity in the mixed rubber and reclaimed rubber.Rubber products with different shapes can be extruded according to customer requirements.
Product Feature
1. Compared with the old process, reducing the use of a rubber mixing mill and one worker, the production cost is greatly reduced.And the feeding effect is good, the filtration ability is strong, greatly reduces the work intensity of worker,
reduces the investment cost.

2. Adopt double heads with filter plate,and The filter screen is replaced by hydraulic push, and the operation is fast, not
leaking, saving time and energy.

3. Adopt Hard tooth speed reducer special used on extruder,Low noise and long service life.
4. The rotation speed can be adjusted, which can match the speed of the equipment before and after, improve the utilization of resources, more safety and save energy.


5. The machine barrel and screw are made of high quality alloy steel 38CrMoALA, which is treated with nitrification and abrasion resistance.


6. Equipped with automatic cutting rubber device to reduce the labor intensity of workers
Product Paramenters
Model
SXJL-150
SXJL-200
SXJL-250
Motor Power(KW)
Diameter of Screw(mm)
150
200
250
5.5
Length-diameter Ratio of Screw(L/D)
5.14:1
4.5:1
4:1
15
Screw Rotational Speed(RPM)
53
45
40
160
Motor Power(KW)
37/45
55/75
110
245
Product packaging
Equipment painting completed before delivery, and then wrapped with stretch film, avoid rubbing the paint off the surface, wooden packaging can be customized, key parts, such as electronic control box, will be wrapped by shockproof packaging materials, and then packed in wooden cases.
FAQ
1. What does your factory do regarding quality control?

We pay much more importance to quality control from the very beginning to the end of production. Every machine will be fully assembled and carefully tested before shipment.

2. What's the machine quality guarantee?

Quality guarantee time is one year.We choose world famous brand components to keep our machine in perfect working condition.

3. Are you able to give installation and commissioning overseas?How long time will it take?

Yes, we can supply overseas service and technical support but customer needs to pay for the cost of the installation. Small machine usually takes within 2~3 days. Big production line usually takes about 30 days.

4. How can I trust you to deliver the right machine as I ordered?

We will absolutely deliver a good quality machine as we discussed and confirmed in the order. The core of our company culture is
innovation,quality,integrity and efficiency. Also we have had many good cooperation with world famous rubber production
manufacturers.If you come to our factory, we can show the user around us.

5. How can we go to your side?

We are located in Qingdao City, Shandong province, China. The name of airport is Qingdao Jiaodong airport. We will pick up you at
the airport.

Before leaving factory, this plate vulcanizing press needs to pass 24 hours' pressure test, pressure maintaining to test the
bearing of the hydro-cylinder and piston stroke and guarantee no oil leakage and seeping to avoid unnecessary quality problems.

Our Services And Certifications
♦ Our engineers can design target machines for customers and send them the drawing to confirm. We are always on the side of saving your cost.
♦ In the process of production, we will take photos and send to customers for their track the progress.
♦ Documents such as packing list, commercial invoice, and bill of lading etc. will be sent after the delivery.
♦ We could supply free English foundation DWG, installation drawing, user guide, maintenance manual and part drawing.
♦ We supply overseas engineer service and help to train your workers to operate the machine.
