Quick Details
-
Brand Name:
-
gol
-
Model Number:
-
GLC-1000W
-
Output Frequency:
-
50/60Hz
-
Size:
-
61*21.6*15.1 cm
-
Weight:
-
4.8kg
-
Switching method:
-
Mains priority
-
Output waveform:
-
Pure sine wave
-
Output efficiency:
-
Up to 94.2%
-
Intelligent cooling method:
-
Smart fan cooling
-
charging method:
-
Three-stage charging method
-
Certificate:
-
CE ROHS
Quick Details
-
Output Current:
-
4.4A
-
Customized support:
-
other
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
gol
-
Model Number:
-
GLC-1000W
-
Output Frequency:
-
50/60Hz
-
Size:
-
61*21.6*15.1 cm
-
Weight:
-
4.8kg
-
Switching method:
-
Mains priority
-
Output waveform:
-
Pure sine wave
-
Output efficiency:
-
Up to 94.2%
-
Intelligent cooling method:
-
Smart fan cooling
-
charging method:
-
Three-stage charging method
-
Certificate:
-
CE ROHS
Product Description
Specification
|
Product number
|
GLC1000-12-1
|
GLC1000-12-2
|
GLC1000-24-1
|
GLC1000-24-2
|
GLC1000-48-1
|
GLC1000-48-2
|
|||||
|
Switching method
|
Mains priority
|
|
|
|
|
|
|||||
|
Switching time
|
≤10ms
|
|
|
|
|
|
|||||
|
Input voltage range
|
85-145VAC
|
180-265VAC
|
85-145VAC
|
180-265VAC
|
85-145VAC
|
180-265VAC
|
|||||
|
recharging current
|
20A
|
|
10A
|
|
5A
|
|
|||||
|
charging method
|
Three-stage charging method
|
|
|
|
|
|
|||||
|
Charging instructions
|
The green indicator light flashes when charging, and it is always on when fully charged. The red light is always on when the
battery is not connected. |
|
|
|
|
|
|||||
|
rated power
|
1000W
|
|
|
|
|
|
|||||
|
Peak power
|
2000W
|
|
|
|
|
|
|||||
|
Input voltage
|
12VDC
|
|
24VDC
|
|
48VDC
|
|
|||||
|
The output voltage
|
110VAC±5%
|
220VAC±5%
|
110VAC±5%
|
220VAC±5%
|
110VAC±5%
|
220VAC±5%
|
|||||
|
USB output
|
5V 1000MA
|
|
|
|
|
|
|||||
|
frequency
|
50HZ±3 or 60HZ±3 switch
|
|
|
|
|
|
|||||
|
Output waveform
|
Pure sine wave
|
|
|
|
|
|
|||||
|
Soft start
|
Yes
|
|
|
|
|
|
|||||
|
Wave distortion
|
THD<3%
|
|
|
|
|
|
|||||
|
Output efficiency
|
Up to 94.2%
|
|
|
|
|
|
|||||
|
No-load current (less than)
|
1A
|
1A
|
0.6A
|
0.6A
|
0.3A
|
0.3A
|
|||||
|
Input voltage range
|
10V-15V
|
10V-15V
|
20V-31V
|
20V-31V
|
40V-60V
|
40V-60V
|
|||||
|
Undervoltage alarm value
|
10±0.5V
|
|
21±0.5V
|
|
41±1V
|
|
|||||
|
Undervoltage protection value
|
9.5±0.5V
|
|
20±0.5V
|
|
40±1V
|
|
|||||
|
Undervoltage recovery value
|
12±0.5V
|
|
24±0.5V
|
|
48±1V
|
|
|||||
|
Overvoltage protection value
|
15±0.5V
|
|
31±0.5V
|
|
60±1V
|
|
|||||
|
Overvoltage recovery value
|
14.5±0.5V
|
|
29±0.5V
|
|
59±1V
|
|
|||||
|
Intelligent cooling method
|
Smart fan cooling
|
|
|
|
|
|
|||||
|
Protective function
|
Battery under voltage, over voltage protection, output overload protection, over temperature protection, short circuit protection,
anti-reverse connection protection (optional) |
|
|
|
|
|
|||||
|
Circuit topology
|
High frequency chain
|
|
|
|
|
|
|||||
|
Operating temperature
|
(-10℃+60℃ civil grade, -25℃+60℃ industrial grade, -40℃+70℃ military grade, temperature can be adjusted)
|
|
|
|
|
|
|||||
|
Storage temperature
|
(-30℃-70℃)
|
|
|
|
|
|
|||||
|
humidity
|
Maximum 90%, no condensation
|
|
|
|
|
|
|||||
|
Warranty
|
2 years
|
|
|
|
|
|
|||||
|
Product Size
|
40*16.5*9/cm
|
|
|
|
|
|
|||||
|
Package Size
|
48*22.5*14.5/cm
|
|
|
|
|
|
|||||
|
Net weight/Gross weight
|
3.98kg/4.87kg
|
|
|
|
|
|
|||||
|
Qty
|
4pcs
|
|
|
|
|
|
|||||
|
Carton size
|
49.5*48*31.5/cm
|
|
|
|
|
|
|||||
|
FCL weight
|
19.48kg
|
|
|
|
|
|
|||||
