Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
Chinese famous brand
-
Dimension(L*W*H):
-
778*634*912 mm
-
Weight:
-
350
-
Rated power/speed:
-
47KW/1500RPM
-
Product name:
-
diesel engine for marine
-
Brand:
-
Chinese famous brand Cumins
-
Model:
-
4BT3.9
Quick Details
-
Displacement:
-
3.9 L
-
Emission Standard:
-
Euro 3
-
Power:
-
47 KW
-
Place of Origin:
-
China
-
Brand Name:
-
Chinese famous brand
-
Dimension(L*W*H):
-
778*634*912 mm
-
Weight:
-
350
-
Rated power/speed:
-
47KW/1500RPM
-
Product name:
-
diesel engine for marine
-
Brand:
-
Chinese famous brand Cumins
-
Model:
-
4BT3.9
Video Description
Product Parameters
|
Engine Type
|
In-line, 4 Cylinders
|
|
|
Number of Cylinders
|
4 Cylinders
|
|
|
Displacement
|
3.9 L (239.0 cu.in.)
|
|
|
Bore and Stroke
|
4.02 in. x 4.72 in
|
|
|
Compression Ratio
|
16.5:1
|
|
|
Oil System Capacity
|
9.0 L (10.0 U.S.qt.)
|
|
|
Coolant Capacity
|
Coolant Capacity
|
|
|
Length
|
30.6 in. (778 mm)
|
|
|
Width
|
25.0 in. (634 mm)
|
|
|
Height
|
35.9 in. (912 mm)
|
|
|
Weight
|
782 lbs. (355 kg)
|
|
|
|
|
|
|
Engine Model
|
Rated Power
HP/RPM |
Peak Torque
LB-FT/RPM |
|
B3.9-75
|
75 / 2200
|
201 / 1200
|
|
B3.9-80
|
80 / 2500
|
201 / 1200
|
|
B3.9- 90
|
90 / 2500
|
254 / 1500
|
|
B3.9- 95
|
95 / 2200
|
283 / 1500
|
|
B3.9-100
|
100 / 2200
|
298 / 1500
|
|
B3.9-110
|
110 / 2200
|
377 / 1300
|
|
B3.9-110
|
110 / 2500
|
275 / 1500
|
|
B3.9-116
|
116 / 2500
|
300 / 1500
|
|
B3.9-125
|
125 / 2200
|
350 / 1500
|
|
B3.9-130
|
130 / 2500
|
344 / 1500
|
