The multi-linked film reel is used to coordinate the film pulling process, which is suitable for multi-roll film materials, the film pulling is smooth and not stuck.
Contact us For product pricing, customization, or other inquiries:
Contact Us
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Weight (KG):
-
300
-
Voltage:
-
220v
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
OCEAN
-
Dimension(L*W*H):
-
3370*670*1450
-
Name:
-
fruit and vegetable package machine
-
Bag type:
-
Back Sealing vegetable package machine
-
Film width:
-
250/350/450/600/800mm
-
Bag length:
-
65-6000mm fruit pack machine
-
Bag width:
-
30-400mm
-
Product height:
-
65-100mm
-
Packaging materials:
-
OPP,CPP,KOP,ALU-FILM
-
Power:
-
220V,50/60Hz
-
Material:
-
Stainless Steel 304 lettuce pack machine
-
Advantage:
-
Automatic Wrapping Packing Sealing
Quick Details
-
Function:
-
Wrapping, Sealing
-
Packaging Type:
-
Bags, Pouch
-
Packaging Material:
-
Plastic
-
Weight (KG):
-
300
-
Voltage:
-
220v
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
OCEAN
-
Dimension(L*W*H):
-
3370*670*1450
-
Name:
-
fruit and vegetable package machine
-
Bag type:
-
Back Sealing vegetable package machine
-
Film width:
-
250/350/450/600/800mm
-
Bag length:
-
65-6000mm fruit pack machine
-
Bag width:
-
30-400mm
-
Product height:
-
65-100mm
-
Packaging materials:
-
OPP,CPP,KOP,ALU-FILM
-
Power:
-
220V,50/60Hz
-
Material:
-
Stainless Steel 304 lettuce pack machine
-
Advantage:
-
Automatic Wrapping Packing Sealing
Grape Leaf Flow Bar Vegetable Cracker Pillow Roll Wrapping Mini Machine for Horizontal Bag Package
Product Description
Specification
|
Model
|
OC-ZBJ-250S
|
OC-ZBJ-250X
|
OC-ZBJ-350S
|
OC-ZBJ-350X
|
|
Film width
|
Max：250mm
|
Max：250mm
|
Max：350mm
|
Max：350mm
|
|
Bag length
|
65-190mm120-280mm
|
65-6000mm
|
90-330mm
|
90-330mm
|
|
Bag width
|
30-120mm
|
30-120mm
|
30-160mm
|
30-160mm
|
|
Product height
|
Max：65mm
|
Max：65mm
|
Max：70mm
|
Max：70mm
|
|
Film roll diameter
|
Max：250mm
|
Max：320mm
|
Max：320mm
|
Max：320mm
|
|
Packaging speed
|
30-180bag/min
|
30-180bag/min
|
60-120bag/min
|
30-120bag/min
|
|
Packaging materials
|
OPP, OPP/CPP, KOP/CPP, ALU-FILM
|
OPP, OPP/CPP, KOP/CPP, ALU-FILM
|
OPP, OPP/CPP, KOP/CPP, ALU-FILM
|
OPP, OPP/CPP, KOP/CPP, ALU-FILM
|
|
Power
|
220V 50/60Hz 2.4KW
|
220V 50/60Hz 2.4KW
|
220V 50/60Hz 2.4KW
|
220V 50/60Hz 2.4KW
|
|
Machine size
|
3370*670*1450mm
|
3370*670*1450mm
|
3960*770*1450mm
|
3960*770*1450mm
|
|
Machine weight
|
300Kg
|
300Kg
|
350Kg
|
350Kg
|
|
Model
|
OC-ZBJ-450S
|
OC-ZBJ-450X
|
OC-ZBJ-600S
|
OC-ZBJ-600X
|
|
Film width
|
Max：450mm
|
Max：450mm
|
Max：600mm
|
Max：600mm
|
|
Bag length
|
130-450mm
|
130-6000mm
|
130-450mm
|
150-6000mm
|
|
Bag width
|
60-200mm
|
60-200mm
|
80-280mm
|
80-280mm
|
|
Product height
|
Max：90mm
|
Max：90mm
|
Max：110mm
|
Max：100mm
|
|
Film roll diameter
|
Max：320mm
|
Max：320mm
|
Max：400mm
|
Max：320mm
|
|
Packaging speed
|
25-120bag/min
|
25-120bag/min
|
20-100bag/min
|
20-80bag/min
|
|
Packaging materials
|
OPP, OPP/CPP, KOP/CPP, ALU-FILM
|
OPP, OPP/CPP, KOP/CPP, ALU-FILM
|
OPP, OPP/CPP, KOP/CPP, ALU-FILM
|
OPP, OPP/CPP, KOP/CPP, ALU-FILM
|
|
Power
|
220V 50/60Hz 2.6KW
|
220V 50/60Hz 2.6KW
|
220V 50/60Hz 3KW
|
220V 50/60Hz 3KW
|
|
Machine size
|
4020*820*1450mm
|
4020*820*1450mm
|
4380*970*1500mm
|
4380*970*1500 mm
|
|
Machine weight
|
300Kg
|
300Kg
|
300Kg
|
300Kg
|
|
Model
|
OC-DMZB-600XQD
|
OC-DMZB-800X
|
|
Film width
|
Max：600mm
|
Max：800mm
|
|
Bag length
|
150-6000mm
|
150-6000mm
|
|
Bag width
|
80-280mm
|
100-400mm
|
|
Product height
|
Max：150mm
|
Max：100mm
|
|
Film roll diameter
|
Max：320mm
|
Max：300mm
|
|
Packaging speed
|
10-60bag/min
|
25-150bag/min
|
|
Packaging materials
|
OPP, OPP/CPP, KOP/CPP, ALU-FILM
|
OPP,OPP/CPP,KOP/CPP,ALU-FILM
|
|
Power
|
220V 50/60Hz 2.4KW
|
220V 50/60Hz 4.5KW
|
|
Machine size
|
4200*1000*1450mm
|
4300*1200*1500 mm
|
|
Machine weight
|
500Kg
|
650Kg
|
Product Details
Supports multiple languages, easy to use and can store multiple sets of parameters.
Customized on demand, the material contact parts are made of food-grade materials, which meet hygienic standards.
The rotary constant temperature hot air cutter seals both ends of the product to avoid folded edges and air leakage at the seal.
Safety first, in response to unexpected situations, the machine can be stopped in an emergency.
Provide automatic printing product production date, filling gas and other functions.
