Quick Details
-
Model Number:
-
SQ5
-
Rated Current:
-
100
-
Certificate:
-
CE
-
Pole:
-
3P/4P
-
Change over time:
-
100A 1S/0.5S
-
Rated current:
-
16-3200A
-
Future:
-
Double complex Contact,Zero Arc,distinct on&off Position indicator
-
Quality guarantee::
-
3Years
-
Rated voltage::
-
380V
-
Operation type::
-
automatic and manual
Quick Details
-
Type:
-
CB
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
GFF
-
Model Number:
-
SQ5
-
Rated Current:
-
100
-
Certificate:
-
CE
-
Pole:
-
3P/4P
-
Change over time:
-
100A 1S/0.5S
-
Rated current:
-
16-3200A
-
Future:
-
Double complex Contact,Zero Arc,distinct on&off Position indicator
-
Quality guarantee::
-
3Years
-
Rated voltage::
-
380V
-
Operation type::
-
automatic and manual
| Conventional thermal current lth A | 250A | |||
| Rated current ln(A) | 200A | 250A | ||
| Rated impulse withstand voltage Ui(A) | 500 | 500 | ||
| Dielectric strength(V) | 5000 | 5000 | ||
| Rated surge-resistant voltage Uimp kV(installed category IV) | 8 | 8 | ||
| Rated Working current le(A) | 380A | AC-31 | 200 | 250 |
| AC-33 | 200 | 250 | ||
| AC-35 | 200 | 250 | ||
| 220A | DC-31 | 200 | 250 | |
| DC-33 | 160 | 200 | ||
| DC-35 | 200 | 250 | ||
| Motor power P(380V)kW | 100 | 132 | ||
| Rated short-time withstand current(kA Rms)0.1S/1S | 25/12 | 25/12 | ||
| Rated breaking capbility(A Rms)AC33 380V | 1600 | 1600 | ||
| Rated making capability(A Rms)AC33 380V | 2000 | 2000 | ||
| Rated short-current making capability lcm(kA peak value) | 17 | 17 | ||
| Mechanical durability(number of cyclic operation) | 10000 | 10000 | ||
| Electric durability | COSφ=0.65 AC33 | 1000 | 1000 | |
| Change-oner time | I-0-II or II-0-I (s) | 1.1 | 1.1 | |
| I-0 or II-0 (s) | 0.7 | 0.7 | ||
| 24V(DC)(w) | 75 | 75 | ||
| Moment of operation(Nm) | 30 | 30 | ||
| Weight(kg) | 3poles | 10.4 | 10.4 | |
| 4poles | 11.3 | 11.3 | ||
