Quick Details
-
Voltage:
-
380v / 220v
-
Power:
-
4kw
-
Weight:
-
500 kg
-
Dimension(L*W*H):
-
2300*700*1000mm
-
Name:
-
XMY6/450
-
Product name:
-
Pure material filter clay filter press
-
Filter plate specification:
-
450 mm
-
Volume of the filter chamber:
-
60 L
-
Machine weight:
-
500 kg
-
Machine type:
-
Chamber Filte Press
-
Filtering area:
-
6 m2
-
Thickness of the pressed cake:
-
30 mm
-
Filter press:
-
1 Mpa
-
Plate number:
-
9 pcs
Quick Details
-
Marketing Type:
-
New Product 2023
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Gaodetec
-
Voltage:
-
380v / 220v
-
Power:
-
4kw
-
Weight:
-
500 kg
-
Dimension(L*W*H):
-
2300*700*1000mm
-
Name:
-
XMY6/450
-
Product name:
-
Pure material filter clay filter press
-
Filter plate specification:
-
450 mm
-
Volume of the filter chamber:
-
60 L
-
Machine weight:
-
500 kg
-
Machine type:
-
Chamber Filte Press
-
Filtering area:
-
6 m2
-
Thickness of the pressed cake:
-
30 mm
-
Filter press:
-
1 Mpa
-
Plate number:
-
9 pcs
Product Overview
Hydraulic filter press used with Pug mill
This model is used to filter clay, because of its 4kw power, can be used in household workshops, etc., is a good helper in the production of ceramics, but also the favorite product of many small companies.
Product Features
Hydraulic pressure filter press using electric contact pressure gauge to maintain pressure, easy operation, stable, reliable structure, suitable for larger filter area filter press.
Technical Parameters
|
Type
|
Filter area(m²）
|
Filter plate size (mm)
|
Chamber Volume
(L)
|
Plate No.
(pcs)
|
Motor power(kw)
|
Weight
(kg)
|
Demension
L*W*H (mm)
|
|
XMY4/450
|
4
|
450*450
|
60
|
9
|
2.2
|
886
|
1950*700*900
|
|
XMY6/450
|
6
|
450*450
|
91
|
14
|
|
910
|
2200*700*900
|
|
XMY8/450
|
8
|
450*450
|
121
|
19
|
|
960
|
2450*700*900
|
|
XMY10/450
|
10
|
450*450
|
151
|
24
|
|
1010
|
2700*700*900
|
|
XMY12/450
|
12
|
450*450
|
182
|
29
|
|
1060
|
2950*700*900
|
|
XMY15/450
|
15
|
450*450
|
225
|
36
|
|
1130
|
3300*700*900
|
|
XMY16/450
|
16
|
450*450
|
243
|
39
|
|
1160
|
3450*700*900
|
|
XMY15/630
|
15
|
630*630
|
226
|
18
|
|
1725
|
2640*900*1100
|
|
XMY20/630
|
20
|
630*630
|
297
|
24
|
|
1993
|
2940*900*1100
|
|
XMY30/630
|
30
|
630*630
|
452
|
37
|
|
2360
|
3590*900*1100
|
|
XMY40/630
|
40
|
630*630
|
595
|
49
|
|
2788
|
4300*900*1100
|
|
XMY30/870
|
30
|
870*870
|
460
|
23
|
|
2580
|
3180*1200*1300
|
|
XMY40/870
|
40
|
870*870
|
595
|
30
|
|
2925
|
3570*1200*1300
|
|
XMY50/870
|
50
|
870*870
|
748
|
38
|
|
2700
|
4110*1200*1300
|
|
XMY60/870
|
60
|
870*870
|
902
|
46
|
|
2980
|
4550*1200*1300
|
|
XMY70/870
|
70
|
870*870
|
1056
|
54
|
|
3250
|
4990*1200*1300
|
|
XMY80/870
|
80
|
870*870
|
1210
|
62
|
|
4561
|
5430*1200*1300
|
