Quick Details
-
Brand Name:
-
CFKGCN
-
Model Number:
-
HGLZ1-160
-
Product name:
-
isolator switch
-
Color:
-
white
-
Certificate:
-
CE
-
Function:
-
used to AC
-
amp:
-
10A to 3150A
-
volt:
-
AC 660V
-
Cable Standard:
-
2.5mm2 4.0mm2 6.0mm2
-
Gende:
-
silver point
-
Connecting system:
-
Crimp connection
-
Standard:
-
IEC60947-3
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
660V
-
Place of Origin:
-
zhejiang
-
Brand Name:
-
CFKGCN
-
Model Number:
-
HGLZ1-160
-
Product name:
-
isolator switch
-
Color:
-
white
-
Certificate:
-
CE
-
Function:
-
used to AC
-
amp:
-
10A to 3150A
-
volt:
-
AC 660V
-
Cable Standard:
-
2.5mm2 4.0mm2 6.0mm2
-
Gende:
-
silver point
-
Connecting system:
-
Crimp connection
-
Standard:
-
IEC60947-3
| Overall dimension | |||||||||||||||||
| In | B | C | D | E | J 1 | J2 | N | P | R | S | U | φX | Y | J | K | ||
| 125A/3 | 135 | 147 | 156 | 83 | 29 | 195 | 28 | 36 | 20 | 25 | 115 | 9 | 55 | 120 | 95 | ||
| 125A/ 4 | 135 | 147 | 156 | 83 | 29 | 225 | 22 | 36 | 20 | 25 | 115 | 9 | 55 | 150 | 95 | 7 | |
| 160A/3 | 135 | 147 | 156 | 83 | 29 | 195 | 28 | 36 | 20 | 25 | 115 | 9 | 55 | 120 | 95 | ||
| 160A/ 4 | 135 | 147 | 156 | 83 | 29 | 225 | 22 | 36 | 20 | 25 | 115 | 9 | 55 | 150 | 95 | ||
| 200A/3 | 170 | 167 | 166 | 95 | 30 | 235 | 33 | 50 | 25 | 30 | 140 | 11 | 64 | 160 | 116 | ||
| 200A/ 4 | 170 | 167 | 166 | 95 | 30 | 285 | 33 | 50 | 25 | 30 | 140 | 11 | 64 | 210 | 116 | ||
| 250A/3 | 170 | 167 | 166 | 95 | 30 | 235 | 33 | 50 | 25 | 30 | 140 | 11 | 64 | 160 | 116 | ||
| 250A/ 4 | 170 | 167 | 166 | 95 | 30 | 285 | 33 | 50 | 25 | 30 | 140 | 11 | 64 | 210 | 116 | ||
| 315A/3 | 240 | 213 | 197 | 129 | 45 | 298 | 42 | 50 | 32 | 40 | 206 | 11 | 84 | 270 | 179 | ||
| 315A/ 4 | 240 | 213 | 197 | 129 | 45 | 358 | 38 | 50 | 32 | 40 | 206 | 11 | 84 | 210 | 179 | ||
| 400A/3 | 240 | 213 | 197 | 129 | 45 | 298 | 42 | 65 | 32 | 40 | 206 | 11 | 84 | 270 | 179 | ||
| 400A/ 4 | 240 | 213 | 197 | 129 | 45 | 358 | 38 | 65 | 32 | 40 | 206 | 11 | 84 | 210 | 179 | ||
