Quick Details
-
Brand Name:
-
CFKGCN
-
Model Number:
-
HH15-100
-
Product name:
-
isolator switch
-
Color:
-
white
-
Certificate:
-
CE
-
Function:
-
used to AC
-
amp:
-
63A to 1250A
-
volt:
-
AC 660V
-
Cable Standard:
-
2.5mm2 4.0mm2 6.0mm2
-
Gende:
-
silver point
-
Connecting system:
-
Crimp connection
-
Standard:
-
IEC60947-3
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
660V
-
Place of Origin:
-
zhejiang
-
Brand Name:
-
CFKGCN
-
Model Number:
-
HH15-100
-
Product name:
-
isolator switch
-
Color:
-
white
-
Certificate:
-
CE
-
Function:
-
used to AC
-
amp:
-
63A to 1250A
-
volt:
-
AC 660V
-
Cable Standard:
-
2.5mm2 4.0mm2 6.0mm2
-
Gende:
-
silver point
-
Connecting system:
-
Crimp connection
-
Standard:
-
IEC60947-3
| Spec HH15 | 63 | 125 | 160 | 250 | 400 | 630 |
| Number of main poles | 3 | |||||
| Rated insulation voltage(V) | Ue=380, Uj=660;Ue=660, Uj=1000 | |||||
| Rated working voltage(V) | AC 380 660 | |||||
| Conventional free air heating current(A) | 63 | 125 | 160 | 250 | 400 | 630 |
| Rated working current/power(IC) 380V AC-23B(A) | 63 | 125 | 160 | 250 | 400 | 630 |
| 660V AC-23B(A) | 63 | 100 | 160 | 250 | 315 | 425 |
| Rated blowout short-circuit current 380V(kA) | 50/100 | |||||
| Rated blowout short-circuit current 660V(kA) | 50 | |||||
| Mechanical life(cycle) | 1700 | 1400 | 1400 | 1400 | 800 | 800 |
| Electric life(cycle) | 300 | 200 | 200 | 200 | 200 | 200 |
| Max.fuse body current(A)380V/660V | 63/63 | 125/100 | 160/160 | 250/250 | 400/315 | 630/425 |
| Knife contact fuse tube Model | 0 | 1--2 | 3 | |||
| (N.m)Operation moment | 7.5 | 16 | 30 | |||
| Auxiliary contact 380VAC-11 | 5 | |||||
