Quick Details
-
Dimension(L*W*H):
-
780*880*1450MM
-
Weight:
-
1050
-
Power (kW):
-
4KW(optional)
-
Crimping range(_mm):
-
6-51mm 1/4-2" 4SP(Customed Production Capabilities)
-
Maximum Open Diameter::
-
150MM
-
Crimping precision(mm):
-
0.01m'm
-
System pressure(Mpa):
-
31.5Mpa
-
Qty of dies(set):
-
11set 14 18 21 26 30 34 38 45 50 57 65(special Dies: optional)
-
Crimping pressure(T):
-
650T
-
Efficiency(pc/h):
-
250pcs/h
-
Output of pump:
-
14L/min
-
Oil Quantity:
-
110L
-
Strock Time::
-
12+2S
Quick Details
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
HENGHUA
-
Voltage:
-
220V 50HZ 1Phase/380V 50HZ 3Phase (can customize)
-
Dimension(L*W*H):
-
780*880*1450MM
-
Weight:
-
1050
-
Power (kW):
-
4KW(optional)
-
Crimping range(_mm):
-
6-51mm 1/4-2" 4SP(Customed Production Capabilities)
-
Maximum Open Diameter::
-
150MM
-
Crimping precision(mm):
-
0.01m'm
-
System pressure(Mpa):
-
31.5Mpa
-
Qty of dies(set):
-
11set 14 18 21 26 30 34 38 45 50 57 65(special Dies: optional)
-
Crimping pressure(T):
-
650T
-
Efficiency(pc/h):
-
250pcs/h
-
Output of pump:
-
14L/min
-
Oil Quantity:
-
110L
-
Strock Time::
-
12+2S
Why Choose Us
Product Description
| Technical specifications | |
| Crimping Range: | 6-51mm 1/4-2" 4SP(Customed Production Capabilities) |
| Dies Quantity: | 11set 14 18 21 26 30 34 38 45 50 57 65(special Dies: optional) |
| Accuracy: | 0.01mm |
| Swept Volume: | 10L |
| System Pressure: | 31.5MPA |
| Output of pump: | 14L/min |
| Motor Power (as your requirements): | 4KW(optional) |
| Voltage (as your requirements): | 220V 50HZ 1Phase/380V 50HZ 3Phase (can customize) |
| Buckling Pressure: | 650T |
| Oil Quantity: | 110L |
| Efficiency: | 250pcs/h |
| Strock Time: | 12+2S |
| Package Dimension: | 780*880*1450MM |
| Net Weight: | 1050KG |
| Gross Weight: | 1080kg |
| Range | ± 60mm |
| Maximum Open Diameter: | 150MM |
| Quickly Change Ststem: | including |
| Foot pedal: | included |
| light: | included |
| Special Dies: | optional |
