● Professional metallurgical objective and plan eyepiece provide clear image, high resolution, comfortable observation.
● Superior image and reliable mechanical structure.
● With the corresponding photo or video accessories, can collect and preserve the image, with computers and specialized metallographic analysis software can analyze the metallographic image.
● Easy to operate, Have all kinds of accessories. Widely used in teaching and research metallographic analysis, semiconductor silicon wafer inspection, geology mineral analysis, precision engineering and surveying fields.
Contact us For product pricing, customization, or other inquiries:
Contact Us
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
MEGA, MEGA
-
Model Number:
-
IMM 3000
-
Product Name:
-
IMM 3000
-
Application:
-
Inspection,Industry Research,PCB
-
Light Source:
-
halogen lamp
-
Micrometer:
-
High Precision Micrometer
-
Head:
-
Trinocular Head, 45° Inclined
-
Optical System:
-
Infinity Color Corrected Optical System
-
Keyword:
-
Optical Microscope
Quick Details
-
Warranty:
-
1years, 1 year
-
Theory:
-
Metallurgical Microscope
-
Drawtube:
-
Trinocular
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
MEGA, MEGA
-
Model Number:
-
IMM 3000
-
Product Name:
-
IMM 3000
-
Application:
-
Inspection,Industry Research,PCB
-
Light Source:
-
halogen lamp
-
Micrometer:
-
High Precision Micrometer
-
Head:
-
Trinocular Head, 45° Inclined
-
Optical System:
-
Infinity Color Corrected Optical System
-
Keyword:
-
Optical Microscope
Our Advantages
Our innovative cut-off machines, mounting presses, grinders, polishers/electrolytic etchers, as well as hardness testers
andanalysis systems provide maximum reliability and fexibility.Thanks to the most advanced engineering technologies andmanufacture of components in our own factory, weare able to fulfll individual customer requirements by adapting our instruments to their needs.
Our R&D department for hard and software works inclose cooperation with our customers to ensure continuous optimization of our products. Customers in more than 30 countries appreciate our comprehensive sales and service network as well as direct communication with our experts.
To provide you with solutions of consistentlyhigh-quality we rely on the expertise and creativityofour qualifed and dedicated long-standingemployees.
Modern production engineering and high vertical integration:
Optimum control of every single component of our machines guarantees
reliable MEGA product quality “made in China”.
Application consultation and end-user seminars with individual focus:
Our application experts ascertain parameters and equipment
confgurations best suited for your sample preparation process.
In-house hardware and software development:
MEGA hosts the complete R&D process in-house to be able to offer
customer-specifc solutions. Tailor-made solutions to meet individual
requirements are our strength.
Product Description
IMM 3000 High-tech Laboratory Trinocular Metallomicroscope Optical System Inverted Metallographic Inspection Microscope
Features:
For different observation
Supporting for bright field, dark field, polarizing and differential interference contrast, IMM5000 is applied for different researches
Dark Field
Plarizing
Differential Interference Contrast (DIC）
Technical Specifications
|
IMM3000 Inverted Microscope
|
|
|
|
|
|
|
||||||
|
Observation
|
Reflected/BF/Polarizing
|
|
|
|
|
|
||||||
|
Optical System
|
Finity color corrected optical system
|
|
|
|
|
●
|
||||||
|
Viewing Head
|
Gemel trinocular，45°inclined，Diopter adjustment ±5 for each side，Interpupillary distance adjustable between：54-75mm，refract rate，
binocular:trinocular =80%:20% |
|
|
|
|
●
|
||||||
|
Eyepiece
|
High eyepoint wide field plan eyepiece PL10X/18mm
|
|
|
|
|
●
|
||||||
|
|
High eyepoint wide field eyepiece WF15X/13
|
|
|
|
|
○
|
||||||
|
|
High eyepoint wide field eyepiece WF20X/10mm
|
|
|
|
|
○
|
||||||
|
LWD plan achromatic Metallurgical objective
|
|
N.A.
|
W.D.
|
Cover Glass
|
Conjugate (mm)
|
|
||||||
|
|
5X
|
0.13
|
15.5mm
|
0
|
195
|
●
|
||||||
|
|
10X
|
0.25
|
8.7mm
|
0
|
195
|
●
|
||||||
|
|
20X
|
0.4
|
8.8mm
|
0
|
195
|
●
|
||||||
|
|
50X
|
0.6
|
5.1mm
|
0
|
195
|
●
|
||||||
|
|
100X
|
0.8
|
2.0mm
|
0
|
195
|
○
|
||||||
|
Nosepiece
|
Reversed quintuple nosepiece
|
|
|
|
|
●
|
||||||
|
Focusing adjustment
|
Low position coaxial coarse and fine adjustment. with tightness adjustment.Coarse adjustment range 38 mm；precision of fine
adjustment:2um |
|
|
|
|
●
|
||||||
|
Stage
|
Three-ply mechanical stage，area 180mmX155mm，right hand low position control，Moving range:75mm×40mm;
|
|
|
|
|
●
|
||||||
|
|
Metal stage plate，center hole dia.φ12mm
|
|
|
|
|
●
|
||||||
|
|
Metal stage plate，center hole dia.φ25mm
|
|
|
|
|
○
|
||||||
|
Illumination system
|
Reflection Koehler illumination with iris diaphragm and centerable field diaphragm ,
|
|
|
|
|
●
|
||||||
|
|
6V/30W halogen bulb with continuous intensity
|
|
|
|
|
●
|
||||||
|
|
Single 5W LED option
|
|
|
|
|
○
|
||||||
|
Filter
|
Blue/Green/Yellow
|
|
|
|
|
○
|
||||||
|
Polarizing kit
|
Polarizer and the analyzer can be removed from the optical path, the analyzer can be rotated 360 °
|
|
|
|
|
○
|
||||||
|
Voltage
|
wide-range voltage 90-240V, 50/60Hz
|
|
|
|
|
●
|
||||||
|
Video accessories
|
CTV0.5X/1.0X
|
|
|
|
|
○
|
||||||
|
Camera
|
USB2.0, 5MP/USB 3.0, 6.3MP/USB3.0 16MP
|
|
|
|
|
○
|
||||||
|
Camera
Software |
It provides functions to fully control the camera and present the video stream processed by Ultra FineTM color engine at high
speed, which includes dedicated pipeline to process the raw data into a realistic scene. Besides, diversified useful tools are provided for specific purpose, such as luminance calibration, measurement, image stitching, extending depth of field, video watermark attachment, color composition, imaging processing and so on. |
|
|
|
|
○
|
||||||
|
Warranty
|
1year
|
|
|
|
|
|
||||||
|
●Standard ○Option
|
|
|
|
|
|
|
||||||
