IC/PC/NFC smart Chip credit card reader writer + all 3 tracks magnetic card reader device system
IC/PC/NFC smart Chip credit card reader writer + all 3 tracks magnetic card reader device system
IC/PC/NFC smart Chip credit card reader writer + all 3 tracks magnetic card reader device system
IC/PC/NFC smart Chip credit card reader writer + all 3 tracks magnetic card reader device system
IC/PC/NFC smart Chip credit card reader writer + all 3 tracks magnetic card reader device system
IC/PC/NFC smart Chip credit card reader writer + all 3 tracks magnetic card reader device system
IC/PC/NFC smart Chip credit card reader writer + all 3 tracks magnetic card reader device system
IC/PC/NFC smart Chip credit card reader writer + all 3 tracks magnetic card reader device system

IC/PC/NFC smart Chip credit card reader writer + all 3 tracks magnetic card reader device system

FOB Reference Price: Get Latest Price
≥1 Pieces
US $66
≥10 Pieces
US $64.9
≥100 Pieces
US $60.5
≥1000 Pieces
US $52.8
Free Inquiry
Customized Request
Contact us For product pricing, customization, or other inquiries:
Contact Us
  • Product Details
  • {{item.text}}

Quick Details

Installation:
Internal
Brand Name:
Sen-Rich
Model Number:
RS160
Place of Origin:
Guangdong, China
Color:
Black
Support cards:
RFID/IC/PSAM
Application:
Reading Stripe Card
Keywords:
Computing Terminal
Feature:
USB Mini Magnetic Stripe Card Reader
Weight:
180g
Support card type:
Credit Card Ect
Host Interface:
USB 2.0 CCID1 (also Compliant
Size:
160mm(L) /45mm(W) / 45mm(H)
Certification:
USB2.0/USB-OTG

Quick Details

Type:
MMC CARD, SM Card
Interface:
usb
Card Slots:
All in 1 / Multi in 1
Installation:
Internal
Brand Name:
Sen-Rich
Model Number:
RS160
Place of Origin:
Guangdong, China
Color:
Black
Support cards:
RFID/IC/PSAM
Application:
Reading Stripe Card
Keywords:
Computing Terminal
Feature:
USB Mini Magnetic Stripe Card Reader
Weight:
180g
Support card type:
Credit Card Ect
Host Interface:
USB 2.0 CCID1 (also Compliant
Size:
160mm(L) /45mm(W) / 45mm(H)
Certification:
USB2.0/USB-OTG
All-in-oneCardReader
All-in-oneCardReader

-Feature-

Magnetic card
Selectable tracks
yes
Read card
1/2/3tracks
Swipe
Double direction
Head life
Approx 500,000 passes
Parity and LRC checking
Built-in, audible and LED good read and error indicator
Cards supported
ISO 7811,AMMVA,CADMV
RFID card
Operating Frequency
13.56 MHz
Smart Card Interface
ISO14443-A, Mifare
Sensing Distance
About 0-5cm
Programmable sound
ON or OFF
Cards supported
ISO14443A,MifareOneS50,MifareOneS70,MF3 DESFIRE, Ultralight, ISO14443B ,SONY felica
PSAM card
Head life
Approx 200,000 passes
Communications
USB
Cards supported
ISO 7816-3
operating system
Win7, Win 2008 ,Vista, Win 2003, Win 2000, XP, Linux
IC Card
Cards supported
AT24C01A/24C02/24C04/24C08/24C16/AT24C64,SLE4432/4442,SLE4418/4428,ISSI 24C01A/16,ISO7816-(1-4) (T=1, T=0)
Communications
USB2.0,USB-OTG(Android 3.1 above)
Swipe speed
3 ~ 60 inches per second
Maximum power consumption
100 mW
Temperature
Commercial-grade:-20°∼ 60 °C;Industrial-grade:-20°∼ 60 °C
Humidity
90% non- condensing
Anti-static interference
15KV
Magnetic interference resistance
19Oersted
Vibration resistance
Amplitude 0.35mm,Frequency 10-55Hz,Three axis directions sweep vibration
Insulation Resistance
Hot and humid circumstances(40°,95%)Insulation resistance should not be less than 5MΩ
Dimensions
160mm(L) ×45mm(W) × 45mm(H)
Weight
180g
