Quick Details
-
Material:
-
Steel
-
Brand Name:
-
OEM Brand
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Server case
-
Size Standard:
-
4U
-
Size:
-
650mm(D)X483mm(W)X176mm(H)
-
Package:
-
sigle package/double package
-
Weight (no hard drive):
-
18 kg(N.W.) 21kg(G.W.)
-
Drive bay:
-
24*3.5" hot swap bays
-
USB:
-
2.0/3.0
-
Switch:
-
Power switch x 1, reset x 1
-
Relative humidity:
-
5% to 95% non-condensing
-
Motherboard:
-
EEB (12"x13"), CEB(12"x10.5"), ATX (12"x9.6"), Micro ATX (9.6" x 9.6")
Quick Details
-
Application:
-
Desktop
-
Type:
-
Rack
-
Form Factor:
-
ATX
-
Material:
-
Steel
-
Brand Name:
-
OEM Brand
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Server case
-
Size Standard:
-
4U
-
Size:
-
650mm(D)X483mm(W)X176mm(H)
-
Package:
-
sigle package/double package
-
Weight (no hard drive):
-
18 kg(N.W.) 21kg(G.W.)
-
Drive bay:
-
24*3.5" hot swap bays
-
USB:
-
2.0/3.0
-
Switch:
-
Power switch x 1, reset x 1
-
Relative humidity:
-
5% to 95% non-condensing
-
Motherboard:
-
EEB (12"x13"), CEB(12"x10.5"), ATX (12"x9.6"), Micro ATX (9.6" x 9.6")
| Drive bay | 24×hot swap SATA/ SAS 6G hard drive bay |
| Cooling fan | 4 x 80mm middle wind wall, 2 x 80mm back board fan |
| switch | power switch x 1, system reboot x 1 |
| Indicator light | power switch x 1, hard drive x 1, network X 2 |
| interface | 2 front board USB port, 6 inner SFF-8087 Mini SAS port, 12 4-pin Redundant power interface |
| Motherboard compatibility | support EEB (12"x13"), CEB(12"x10.5"), ATX (12"x9.6"), Micro ATX (9.6" x 9.6") |
| Optional power supply | standard ATX power, Mini Redundant power (H x W 5.91x3.39 inch) |
| Size (width x depth x height) | (483mm x 650mm x 176mm) |
| package | sigle package/double package |
| Weight (no hard drive) | 18 kg(N.W.) 21.(G.W.) |
| Ambient temperature | 0/40,32/104°F(Working)-20/60Ç,-4/140(non-working) |
| Relative humidity | 5% to 95%, Non-condensing |
