Quick Details
-
Dimension(L*W*H):
-
670(L)*490(W)*780(H)mm
-
Weight:
-
250, 260KG
-
Power (kW):
-
3KW/4KW
-
Crimping range:
-
6-51mm
-
Crimping force:
-
450T
-
Type:
-
DX68
-
Scale accuracy:
-
0.01mm
-
Rated pressure:
-
31.5MPA
-
Oil pump displacement:
-
5ml/rad (380V); 2.5ml/rad (220V)
-
Overall dimensions:
-
670(L)*490(W)*780(H)mm
-
Power(W):
-
3KW/4KW
-
Marketing Type:
-
New Product 2019
Quick Details
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
HENGHUA
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
670(L)*490(W)*780(H)mm
-
Weight:
-
250, 260KG
-
Power (kW):
-
3KW/4KW
-
Crimping range:
-
6-51mm
-
Crimping force:
-
450T
-
Type:
-
DX68
-
Scale accuracy:
-
0.01mm
-
Rated pressure:
-
31.5MPA
-
Oil pump displacement:
-
5ml/rad (380V); 2.5ml/rad (220V)
-
Overall dimensions:
-
670(L)*490(W)*780(H)mm
-
Power(W):
-
3KW/4KW
-
Marketing Type:
-
New Product 2019
Why Choose Us
| Product Parameter | ||||
| Model | DX68 | DX76 | DX102 | DX150 |
| Crimping range | ||||
| Max crimping Force | 449T | 500T | 1400T | 2500T |
| Rated Pressure | 31.5MPa | 50Mpa | 31.5Mpa | 31.5Mpa |
| Weight | 250kg | 300kg | 520kg | 900kg |
| Mold Quantity | 10 sets | 13Sets | 16Sets | 17Sets |
| Power | 3KW/4KW | 4KW | 4KW/5.5KW/7.5KW | 4KW/5.5KW/7.5KW |
| Voltage | 220V/380V | 240V / 380V | 380V or customized | 380V or customized |
| Scale accuracy | 0.01mm | 0.01mm | 0.01mm | 0.01mm |
| Overall dimensions | 670*490*780mm | 730*470*930mm | 900*790*1070mm | 1030*630* 1160mm |
