Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
VMAN
-
Dimension(L*W*H):
-
Standard
-
Weight:
-
1575kg
-
Rated power/speed:
-
360/1500
Quick Details
-
Displacement:
-
std
-
Emission Standard:
-
std
-
Power:
-
360kw
-
Place of Origin:
-
China
-
Brand Name:
-
VMAN
-
Dimension(L*W*H):
-
Standard
-
Weight:
-
1575kg
-
Rated power/speed:
-
360/1500
Product Description
| Requirements of natural gas | ||||||||||
| 1,Methane should be at least 95% | ||||||||||
| 2,The natural gas temperature shoule be between0-60℃ | ||||||||||
| 3,No inpurity should be in the gas.water in the gas should be less than 20g/Nm3 | ||||||||||
| 4,Heat value should be at least 5500kcal/m3,if less than his value,the power of the engine will be declined | ||||||||||
| 5,Gas pressure should be 3-100Kpa,if the pressure is less than 3Kpa,bootster fan is necessary | ||||||||||
| 6,The gas should be dehydrated and desulfurated.make sure that there is no liquid in the gas.H2S<200mg/Nm3 | ||||||||||
| Model | DT11 | DT15 | DT22 | DT30 | |
| prime power (kw/rpm) | 180/1500 | 240/1500 | 360/1500 | 480/1500 | |
| 207/1800 | 276/1800 | 414/1800 | 552/1800 | ||
| Standby power (kw/rpm) | 198/1500 | 264/1500 | 396/1500 | 528/1500 | |
| 227.7/1800 | 303.6/1800 | 455.4/1800 | 607.2/1800 | ||
| cylinder arrangement | V6 | V8 | V12 | V16 | |
| Aspiration | Turbo | Turbo | Turbo | Turbo | |
| Bore*stroke | 128x142 | 128x142 | 128x142 | 128x142 | |
| Displacement(L) | 10.96 | 14.62 | 21.93 | 29.24 | |
| Oil capacity(L) | 25 | 27 | 57 | 78 | |
| Coolant capacity(L) | 19 | 20 | 23 | 26 | |
| Oil consumption(g/kw.h) | 2 | 2 | 2 | 2 | |
| Compression ratio | 10.5:1 | 10.5:1 | 10.5:1 | 10.5:1 | |
