Quick Details
-
Brand Name:
-
TSX
-
Voltage:
-
380V;660V
-
Dimension(L*W*H):
-
9438*6122*5837
-
Weight:
-
59280 KG
-
Product name:
-
Multi Deck Vibrating Screen Ore Classifier Retangular Mechanical Sieve
-
capacity:
-
>1400t/h
-
Material:
-
Q235B
-
Delivery Time:
-
35days
-
Layer(s):
-
2 Layers
-
Feature:
-
High Screening Efficiency
-
Surface treatment:
-
Paint
-
MOQ:
-
1set
-
Usage:
-
Separation Screening
-
Color:
-
Costomized
Quick Details
-
Type:
-
banana vibrating screen
-
Marketing Type:
-
New Product 2021
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
TSX
-
Voltage:
-
380V;660V
-
Dimension(L*W*H):
-
9438*6122*5837
-
Weight:
-
59280 KG
-
Product name:
-
Multi Deck Vibrating Screen Ore Classifier Retangular Mechanical Sieve
-
capacity:
-
>1400t/h
-
Material:
-
Q235B
-
Delivery Time:
-
35days
-
Layer(s):
-
2 Layers
-
Feature:
-
High Screening Efficiency
-
Surface treatment:
-
Paint
-
MOQ:
-
1set
-
Usage:
-
Separation Screening
-
Color:
-
Costomized
Product Description
Specification
|
item
|
TSX-14 Multi Deck Banana Vibrating Screen Ore Classifier Retangular Mechanical Sieve
|
|
Applicable Industries
|
Manufacturing Plant, Construction works , Energy & Mining, Other
|
|
Showroom Location
|
South Africa, Australia
|
|
Video outgoing-inspection
|
Provided
|
|
Machinery Test Report
|
Provided
|
|
Marketing Type
|
New Product 2021
|
|
Warranty of core components
|
1 Year
|
|
Core Components
|
Motor, exciter
|
|
Condition
|
New
|
|
Type
|
banana vibrating screen
|
|
Application
|
Ore
|
|
Place of Origin
|
China
|
|
Brand Name
|
TSX
|
|
Voltage
|
380V;660V
|
|
Dimension(L*W*H)
|
9438*6122*5837
|
|
Weight
|
59280KG
|
|
Warranty
|
1 Year
|
|
Feature
|
High Screening Efficiency
|
|
capacity
|
>1400t/h
|
|
Material
|
Q235B
|
|
Delivery Time
|
35days
|
|
Layer(s)
|
2 Layers
|
|
Color
|
costomized
|
|
Surface treatment
|
Paint
|
|
MOQ
|
1set
|
|
Usage
|
Separation Screening
|
|
Banana Screens Technical Data
|
|
|
|
|
|
|
|
|||||||
|
Model
|
Layer
|
Model of screen deck
|
Power(kw)
|
Capacity(t/h)
50mm |
Feed size (mm)
|
Weight(t)
|
Overall dimension(mm)
|
|||||||
|
ABS1848
|
1
|
1800×4800mm
|
1*18.5kw
|
>200
|
0-300mm
|
6.583
|
5651*2630*2714
|
|||||||
|
ABS1861
|
1
|
1800×6100mm
|
1*22kw
|
>260
|
0-300mm
|
7.208
|
6833*2610*2818
|
|||||||
|
ABS2461
|
1
|
2400×6100mm
|
1*22kw
|
>300
|
0-300mm
|
8.067
|
6853*3216*2786
|
|||||||
|
ABS3061
|
1
|
3000×6100mm
|
1*30kw
|
>350
|
0-300mm
|
11.1
|
6862*3870*2847
|
|||||||
|
ABS3661
|
1
|
3600×6100mm
|
1*30kw
|
>450
|
0-300mm
|
13.004
|
6867*4500*2895
|
|||||||
|
ABS4261
|
1
|
4200×6100mm
|
1*55kw
|
>600
|
0-300mm
|
19.619
|
6895*5140*3482
|
|||||||
|
ABS4985
|
1
|
4900×8500mm
|
1*90kw
|
>900
|
0-300mm
|
29.979
|
9093*5730*4280
|
|||||||
|
ABD1848
|
2
|
1800×4800mm×2
|
1*22kw
|
>350
|
0-300mm
|
10.933
|
5567*2536*3786
|
|||||||
|
ABD3061
|
2
|
3000×6100mm×2
|
1*55kw
|
>400
|
0-300mm
|
11.981
|
6852*3870*3907
|
|||||||
|
ABD3661
|
2
|
3600×6100mm×2
|
1*55kw
|
>500
|
0-300mm
|
23.616
|
6929*4500*4095
|
|||||||
|
ABD4985
|
2
|
4900×8500mm×2
|
2*90kw
|
>1400
|
0-300mm
|
59.280
|
9438*6122*5837
|
|||||||
|
Note: The mesh size can be customized as your request. The layer also can make as your requirement.
|
|
|
|
|
|
|
|
|||||||
