Quick Details
-
Brand Name:
-
Kacon
-
Model Number:
-
HRF-M6
-
Max. Current:
-
10A
-
Color:
-
Yellow
-
Material:
-
Plastic
-
Built-in Switch:
-
V type Micro Switch
-
Rated Current:
-
10A 250VAC
-
Contact Form:
-
1a x 2ea
-
Degree of Protection:
-
IP68
-
Certification:
-
CE, CCC
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Kacon
-
Model Number:
-
HRF-M6
-
Max. Current:
-
10A
-
Color:
-
Yellow
-
Material:
-
Plastic
-
Built-in Switch:
-
V type Micro Switch
-
Rated Current:
-
10A 250VAC
-
Contact Form:
-
1a x 2ea
-
Degree of Protection:
-
IP68
-
Certification:
-
CE, CCC
Specification
| Part Number | HRF-M6 |
| Contact Form | 1a x 2ea |
| Rated Current | 10A 250VAC |
| Built-in Switch | V15F-01C(CE,UL certified) + 24k gold plate |
| Material | Plastic |
| Cable outlet | 0.5mm² × 4 Wire × 2m |
| Certification | CE, CCC |
| Degree of Protection | IP68 |
| Contact Resistance | <50mΩ |
| Insulation Resistance | above 100mΩ at 500VDC |
| Withstand Voltage | ≥2000VAC(one minute) |
| Mechanical Life | above 10 6 times |
| Electrical Life | above 10 5 times |
| Operating Temperature | -25℃ ~ +70℃ |
| Operating Humidity | 45%≤85%RH |
Dimension
Contact Form
