Quick Details
-
Model Number:
-
REP2000
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
36.5*18*0.8CM
-
Weight:
-
4.32/4.96KG
-
Certificate:
-
ROHS CE FCC
-
Country:
-
China
-
Color:
-
golden
-
Input voltage:
-
DC12/24/48V
-
OEM:
-
Accepted
-
Warranty:
-
2 Years
-
Inverter type:
-
Off-grid Inverter
-
Output waveform:
-
Pure Sine Wave Output
-
Application:
-
Solar Power System Home
-
Efficiency:
-
95%
-
OEM&ODM:
-
Avaiable
Quick Details
-
Output Current:
-
according the load
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ROGERELE
-
Model Number:
-
REP2000
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
36.5*18*0.8CM
-
Weight:
-
4.32/4.96KG
-
Certificate:
-
ROHS CE FCC
-
Country:
-
China
-
Color:
-
golden
-
Input voltage:
-
DC12/24/48V
-
OEM:
-
Accepted
-
Warranty:
-
2 Years
-
Inverter type:
-
Off-grid Inverter
-
Output waveform:
-
Pure Sine Wave Output
-
Application:
-
Solar Power System Home
-
Efficiency:
-
95%
-
OEM&ODM:
-
Avaiable
Product Description
| Model | REP-2000 | |||||||||
| Rated power | 2000W | |||||||||
| Peak power | 4000W | |||||||||
| Input voltage | DC12V | DC24V | DC48V | |||||||
| Output voltage | 100VAC or 110VAC or 120VAC or 220VAC or 230VAC or 240VAC±5% | |||||||||
| Unload current less than | 0.4A | 0.3A | 0.2A | |||||||
| Output frequency | 50Hz±0.5Hz or 60Hz±0.5Hz | |||||||||
| Waveform distortion | THD<3%(Linear load) | |||||||||
| USB port | 5V 1A | |||||||||
| Max.efficiency | 90% | |||||||||
| Input voltage range | 10-15.5V | 20-31V | 40-61V | |||||||
| Low voltage alarm | 10.5±0.5V | 21±0.5V | 42±1V | |||||||
| Low voltage protection | 10±0.5V | 20±0.5V | 40±15V | |||||||
| Over voltage protection | 15.5±0.5V | 31±0.5V | 61±1V | |||||||
| Low voltage recover | 12.3±0.5V | 24±0.5V | 48±1V | |||||||
| Over voltage recover | 14.8V±0.5V | 29.5V±0.5V | 59V±1V | |||||||
| Protect function | Low voltage | Alarm at first, voltage continuously reduce. LED Red light on & shut down | ||||||||
| Over voltage | LED Red light on, shut down | |||||||||
| Over load | LED Red light on, shut down | |||||||||
| Over temperature | Alarm at first, tempurature continuously rise. LED Red light on & shut down | |||||||||
| Short circuit | LED Red light on | |||||||||
| Input reverse polarity | Fuse burn-out | |||||||||
| Working temperature | .-10°-+50. | |||||||||
| Storage temperature | .-30°-+ 70° | |||||||||
| (LxWxH) Dimension(mm) | 395x180x80 | |||||||||
| Packing(mm) | 440x240x145 | |||||||||
| Net./gross weight(g) | 4320/4960 | |||||||||
| QTY/Cth | 4Pcs | |||||||||
| Meas.Ctn(mm) | 500*297*465 | |||||||||
| Warranty | 2 years | |||||||||
| Cooling method | ||||||||||
