Quick Details
-
Ejector Force(kN):
-
80 kN
-
Theoretical Shot Volume(cm³):
-
785 cm³
-
Injection Rate (g/s):
-
10 g/s
-
Injection Weight (g):
-
1500 g
-
Screw Speed (rpm):
-
1 - 178 rpm
-
Screw diameter (mm):
-
70 mm
-
Weight (KG):
-
15000
-
Place of Origin:
-
Fujian, China
-
Open Stroke(mm):
-
320 mm
-
Model Number:
-
MLR-P124F
-
Brand Name:
-
MLR
-
Power (kW):
-
56 kW
-
Color:
-
Single Color
-
Station:
-
24 Stations
-
Structure:
-
Rotary table
-
Mould Size:
-
380*220mm
-
Net Tank Capacity:
-
720L
-
Machine dimension(L*W*H):
-
5335*3250*2360mm
-
Application:
-
Slipper, Sandals, Clog, Soles
-
Raw material:
-
PVC, TPR, PCU
-
Plastic Type:
-
Thermoplastic
-
Clamping Force (kN):
-
45 kN
-
Certification:
-
CE
Quick Details
-
Plasticizing Capacity(g/s):
-
780
-
Mold Height(mm):
-
40 - 260 mm
-
Ejector Stroke(mm):
-
210 mm
-
Ejector Force(kN):
-
80 kN
-
Theoretical Shot Volume(cm³):
-
785 cm³
-
Injection Rate (g/s):
-
10 g/s
-
Injection Weight (g):
-
1500 g
-
Screw Speed (rpm):
-
1 - 178 rpm
-
Screw diameter (mm):
-
70 mm
-
Weight (KG):
-
15000
-
Place of Origin:
-
Fujian, China
-
Open Stroke(mm):
-
320 mm
-
Model Number:
-
MLR-P124F
-
Brand Name:
-
MLR
-
Power (kW):
-
56 kW
-
Color:
-
Single Color
-
Station:
-
24 Stations
-
Structure:
-
Rotary table
-
Mould Size:
-
380*220mm
-
Net Tank Capacity:
-
720L
-
Machine dimension(L*W*H):
-
5335*3250*2360mm
-
Application:
-
Slipper, Sandals, Clog, Soles
-
Raw material:
-
PVC, TPR, PCU
-
Plastic Type:
-
Thermoplastic
-
Clamping Force (kN):
-
45 kN
-
Certification:
-
CE
Our Mission
Product Description
| Model | Unit | MLR-P124F | MLR-P124H |
| Material | PVC | PVC/TPR | PVC/TPR |
| Work stations | station | 24 stations | 24 stations |
| Screw Diameter | MM | 70 | 70 |
| Mould Size | Mm | 380*220 | 380*220 |
| Mould Thickness | Mm | 40 ~ 260 | 65~260 |
| Injection Cap.(Max) | ml | 780 | 780 |
| Injection Pressure | Mpa | 72 | 72 |
| Screw Speed | r/min | 0~178 | 0~ 178 |
| Clamping Force | T | 45 | 45 |
| Barrel Heater Power | Kw | 10.5 | 10.5 |
| Total Installed Capacity of Power | Kw | 29 | 29 |
| Net Tank Capacity | L | 720 | 720 |
| Dimension L*W*H | mm | 5335*3250*2360 | 5335*3250*2360 |
| Machine Weight | Kg | 18000 | 18000 |
