Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Kinggle
-
Year:
-
latest
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
6.2*3.8*4.6(m)
-
Hollow part volume:
-
60L
-
Screw L/D Ratio:
-
24
-
Screw diameter (mm):
-
100 mm
-
Screw Heating Power(kW):
-
6.6 kW
-
Extruder Motor Power(kW):
-
11 kW
-
Mold Platen Size(Width)(mm):
-
300 mm
-
Mold Platen Size(Height)(mm):
-
350 mm
-
Air Pressure(MPa):
-
0.6 MPa
-
Air Comsumption(m³/min):
-
0.4 m³/min
-
Die Head Heating Power(kW):
-
54 kW
-
Accumulator Capacity(L):
-
6.6 L
-
Power (kW):
-
15
-
Weight (T):
-
18
-
Model Number:
-
KGB2D
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Machine type:
-
High Speed Plastic Bottle Making Machine
-
Use:
-
Hollow Moulding
-
Material:
-
HDPE LDPE LLDPE
-
Weight:
-
18Ton
-
Certification:
-
CE ISO
Quick Details
-
Clamping Force (kN):
-
61
-
Output (kg/h):
-
35 kg/h
-
Application:
-
120L drum, bottle, safety seat, float etc
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Kinggle
-
Year:
-
latest
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
6.2*3.8*4.6(m)
-
Hollow part volume:
-
60L
-
Screw L/D Ratio:
-
24
-
Screw diameter (mm):
-
100 mm
-
Screw Heating Power(kW):
-
6.6 kW
-
Extruder Motor Power(kW):
-
11 kW
-
Mold Platen Size(Width)(mm):
-
300 mm
-
Mold Platen Size(Height)(mm):
-
350 mm
-
Air Pressure(MPa):
-
0.6 MPa
-
Air Comsumption(m³/min):
-
0.4 m³/min
-
Die Head Heating Power(kW):
-
54 kW
-
Accumulator Capacity(L):
-
6.6 L
-
Power (kW):
-
15
-
Weight (T):
-
18
-
Model Number:
-
KGB2D
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Machine type:
-
High Speed Plastic Bottle Making Machine
-
Use:
-
Hollow Moulding
-
Material:
-
HDPE LDPE LLDPE
-
Weight:
-
18Ton
-
Certification:
-
CE ISO
Technology
| Specifications | Unit | Fixed open-closing type | |
| Machiner model | PXB100A | PXB100B | |
| Material | PE,PP,ABS etc. | ||
| Max container capacity | L | 90 | 120 |
| Machine dimension ( L×W×H ) | M | 5.9 ×3.8×4.5 | 6.2 ×3.8×4.6 |
| Machine Weight | T | 16 | 18 |
| Clamping unit | |||
| Mold platen size ( W×H ) | MM | 1080 ×1000 | 1200×1200 |
| Max mold size ( W ×H ) | MM | 800 ×1000 | 920 ×1200 |
| Power | |||
| Servo oil pump motor power | KW | 18.5 | 18.5 |
| Average energy consumption | KW | 43-50 | 52-60 |
| Blow pressure | Mpa | 0.8 | 1 |
| Extruder unit | |||
| Screw diameter | MM | 100 | 100 |
| Screw L/D ratio | L/D | 24:1 | |
| Melting capacit for HDPE | KG/HR | 160-200 | 160-200 |
| Extruder power | KW | 45 | 55 |
| Die head | |||
| Max die-pin diameter | MM | 520 | 520 |
| Accumulator capacity | L | 12 | 12 |
| Accumulator weight ( HDPE ) | KG | 9 | 9 |
