Quick Details
-
Mold Height(mm):
-
145 - 450 mm
-
Ejector Stroke(mm):
-
100 mm
-
Ejector Force(kN):
-
34.4 kN
-
Theoretical Shot Volume(cm³):
-
238 cm³
-
Injection Rate (g/s):
-
50 g/s
-
Injection Weight (g):
-
20 g
-
Screw Speed (rpm):
-
1 - 222 rpm
-
Screw diameter (mm):
-
40 mm
-
Screw L/D Ratio:
-
20.5
-
Distance between Tie Bars:
-
410*410
-
Weight (KG):
-
3500 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
190 mm
-
Model Number:
-
BS120
-
Brand Name:
-
Borche
-
Power (kW):
-
8.8 kW
-
After-sales Service Provided:
-
Overseas third-party support available
-
Injection pressure:
-
212MPa
-
Color:
-
Customrized
-
LANGUAGE:
-
English
-
Product name:
-
Plastic Injection Moulding Machine
-
Plastic Type:
-
ABS.AS.PS.HIPSPP.LDPE.HDPE.PMMD.PA6.POM.PCPVC.PET.PBT. TPE(PE)
-
Marketing Type:
-
New Product 2020
-
Application:
-
Inserting Plastic Products
-
Keyword:
-
injection molding machine
-
Usage:
-
Injection Molding Machine Making Plastic Injection
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
410mm
-
Distance between Tie Bars(Height)(mm):
-
410mm
-
Plasticizing Capacity(g/s):
-
20
-
Mold Height(mm):
-
145 - 450 mm
-
Ejector Stroke(mm):
-
100 mm
-
Ejector Force(kN):
-
34.4 kN
-
Theoretical Shot Volume(cm³):
-
238 cm³
-
Injection Rate (g/s):
-
50 g/s
-
Injection Weight (g):
-
20 g
-
Screw Speed (rpm):
-
1 - 222 rpm
-
Screw diameter (mm):
-
40 mm
-
Screw L/D Ratio:
-
20.5
-
Distance between Tie Bars:
-
410*410
-
Weight (KG):
-
3500 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
190 mm
-
Model Number:
-
BS120
-
Brand Name:
-
Borche
-
Power (kW):
-
8.8 kW
-
After-sales Service Provided:
-
Overseas third-party support available
-
Injection pressure:
-
212MPa
-
Color:
-
Customrized
-
LANGUAGE:
-
English
-
Product name:
-
Plastic Injection Moulding Machine
-
Plastic Type:
-
ABS.AS.PS.HIPSPP.LDPE.HDPE.PMMD.PA6.POM.PCPVC.PET.PBT. TPE(PE)
-
Marketing Type:
-
New Product 2020
-
Application:
-
Inserting Plastic Products
-
Keyword:
-
injection molding machine
-
Usage:
-
Injection Molding Machine Making Plastic Injection
Product Description
|
DESCRIPTION OF BS120
|
|
|
||
|
MODEL INTERNATIONAL CLASS NO.
|
UNIT
|
BS120
|
||
|
INJECTION UNIT
|
|
|
||
|
SCREW DIAMETER
|
MM
|
40
|
||
|
SHORT VOLUME
|
cm³
|
238
|
||
|
SHOT WEIGHT(PS)
|
g
|
225
|
||
|
SHOT WEIGHT(PS)
|
OZ
|
8
|
||
|
INJEDTION PRESSURE
|
MPa
|
162
|
||
|
SCREW L/D RATIO
|
L/d
|
20.5
|
||
|
INJECTION STROKE
|
mm
|
190
|
||
|
SCREW ROTARY SPEED MAX.
|
rpm/min
|
222
|
||
|
NOZZLE CONTACT FORCE
|
KN
|
30
|
||
|
NOZZLE STROKE
|
mm
|
250
|
||
|
CLAMPING UNIT
|
|
|
||
|
CLAMPING FORCEclamping force
|
KN
|
1200
|
||
|
OPENING STROKE
|
mm
|
340
|
||
|
PLATEN SIZE
|
mm×mm
|
610*610
|
||
|
SPACE BTW.TIE BARS
|
mm×mm
|
410*410
|
||
|
DAYLIGHT MAX.
|
mm
|
790
|
||
|
MOLD THICKNESS(MIN~MAX)
|
mm
|
145-450
|
||
|
EJECTION STROKE
|
mm
|
100
|
||
|
EJECTOR FORCE
|
KN
|
34.4
|
||
|
EJECTOR PIN
|
nuit
|
4+1
|
||
|
POWER UNIT
|
|
|
||
|
SYSTEM PRESSURE
|
Mpa
|
17.5
|
||
|
PUMP MOTOR
|
KW
|
11
|
||
|
HEATING CAPACITY
|
KW
|
8.8
|
||
|
NO.OF HEATER ZONES
|
uint
|
4
|
||
|
GENERAL UNIT
|
|
|
||
|
OIL TANK CAPACITY
|
L
|
180
|
||
|
MACHINE DIMENSIONS
|
m×m×m
|
4.5*1.38*1.73
|
||
|
MACHINE WEIGHT
|
KG
|
3500
|
||
BS component brand list
BS-III machine features
Detailed Images
MOVING PLATEN CLAMPING
SUPER LONG LASTING TIE BAR
INNOVATED INJECTION STRUCTURE
1-Both carriage cylinder and injection adopt linear guider, which guarantee stable and fast movement, injection supporting made by one piece casting, is rigid and compact.
2-Double carriage cylinder insures injection unit better centering, and movement stable.
3-Adopt double - beam - shift structure, the
platform is good to the neutral, the work is more stable
platform is good to the neutral, the work is more stable
MACHINE SIZE
Certifications
Our Service
Pre-Sales Service
After-Sales Service
Packing & Delivery
|
Packaging
|
|
|
|
Size
|
710×240×210
|
|
|
Weight
|
1.9T
|
|
|
Packaging Details
|
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
|
|
|
Packaging
|
|
|
|
Size
|
710×240×210
|
|
|
Weight
|
1.9T
|
|
|
Packaging Details
|
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
|
|
