Quick Details
-
Model Number:
-
SQ3W
-
Max. Current:
-
63A
-
Type:
-
Transfers Switch
-
Standard:
-
CCC, CE
-
Pole:
-
2P/4P
-
Operation:
-
Manual and Auto
-
MCB to use:
-
SCB8 Circuit Breaker
-
Rated current:
-
6-63amp
-
Gurantee period:
-
2 years
-
Packing:
-
Standard Package
-
Web:
-
www.chinasuntree.com
-
Brand:
-
Suntree
Quick Details
-
Max. Voltage:
-
400V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Xinchi/OEM
-
Model Number:
-
SQ3W
-
Max. Current:
-
63A
-
Type:
-
Transfers Switch
-
Standard:
-
CCC, CE
-
Pole:
-
2P/4P
-
Operation:
-
Manual and Auto
-
MCB to use:
-
SCB8 Circuit Breaker
-
Rated current:
-
6-63amp
-
Gurantee period:
-
2 years
-
Packing:
-
Standard Package
-
Web:
-
www.chinasuntree.com
-
Brand:
-
Suntree
Product Introduction
Product Parameters
|
Type
|
SQ3W
|
|
Specification current Ie(A)
|
6/10/16/20/25/32/40/50/63
|
|
Rated operating voltage, Ue (V)
|
AC230V/AC400V
|
|
Rated insulating voltage Ui (V)
|
AC 690V
|
|
Rated impulse withstand voltage (KV)
|
4KV
|
|
Rated short circuit making capacity Icm
|
6KA
|
|
Rated short circuit breaking capacity Icn
|
4.5KA
|
|
Service life
|
5000 times
|
|
Electric equipment grade
|
CB Class
|
|
Controller
|
Type A(basic type)
|
|
Rated control supply voltage,Us(V)
|
230V 50Hz
|
|
Operating transfer time (no time delay)
|
≤3s
|
