Quick Details
-
Brand Name:
-
HM
-
Model Number:
-
HM3806-1
-
Place of Origin:
-
Guangdong, China
-
Horsepower:
-
3-50W
-
Cable Length:
-
10-50cm( other length can be customized)
-
Outlet Size:
-
20mm
-
Power:
-
3-50W
-
Working voltage range:
-
6VDC-24VDC
-
Max static water lift height:
-
11 meters
-
Max static flowrate:
-
1800LPH
-
Water temperature:
-
-40℃ to 75℃
-
IP grade:
-
IP68
-
Pump size:
-
L67.0*W47.0*H190.8(mm)
-
Pump inlet/Outlet size:
-
17.2mm/16.2mm
-
Pump theory:
-
centrifugal water pump
-
Certification:
-
RoHS, ce
Quick Details
-
Application:
-
Automotive Industry, Biofuel Industry, Commercial Buildings, Developing World Water Solutions, District Energy, Drinking water treatment, Family Homes, Food and Beverage Industry, HVAC OEM, Industrial Boilers, Industrial Utilities, Irrigation and Agriculture, Machining, Marine, Metal and Equipment Manufacturers, Mining industry, Pharmaceutical industry, Raw Water Intake, temperature control, Washing and Cleaning, Wastewater Transport and Flood Control, wastewater treatment, Water Distribution, Water Treatment Solutions
-
Pressure:
-
1.1Bar
-
Voltage:
-
6-24V
-
Brand Name:
-
HM
-
Model Number:
-
HM3806-1
-
Place of Origin:
-
Guangdong, China
-
Horsepower:
-
3-50W
-
Cable Length:
-
10-50cm( other length can be customized)
-
Outlet Size:
-
20mm
-
Power:
-
3-50W
-
Working voltage range:
-
6VDC-24VDC
-
Max static water lift height:
-
11 meters
-
Max static flowrate:
-
1800LPH
-
Water temperature:
-
-40℃ to 75℃
-
IP grade:
-
IP68
-
Pump size:
-
L67.0*W47.0*H190.8(mm)
-
Pump inlet/Outlet size:
-
17.2mm/16.2mm
-
Pump theory:
-
centrifugal water pump
-
Certification:
-
RoHS, ce
- Working voltage range: 6-24V DC
- Rated working voltage: 6VDC/12VDC/24VDC (Please choose one, other rated voltage can be customized.)
- Power range: 3-50W
- Water lift: 1-11 meters
- Flow rate: 300-1500 L/H
- Low noise: Within 40db
- Max working temperature: 75degC
- Pump dimensions: 67 .0 *47.0*90.8 (mm)
- Inlet/Outlet OD: 17.2mm / 16.2mm
| HM3806-1 | |
| 6VDC-24VDC | |
| 6VDC/12VDC / 24VDC (Please choose one, other rated voltage can be customized.) | |
| 3~50W | |
| 1~11 meters | |
| 300~1500 L/H | |
| L67.0*W47.0*H90.8 (mm) | |
| ∅20.0 / ∅20.0 (mm) | |
| Brushless DC motor | |
| Clean water, A ntifreeze , Oil | |
| PH value: PH5-10 (weak acid and weak base), workable on land only. NON submersible. | |
| Max noise | Under normal working condition,(10cm over the test instrument) <40 dB |
| Idea lifespan | 30000 hours |
| -40 ℃ to 70 ℃ | |
| Media temperature | 0 ℃ to 75 ℃ ( Under room temperature surroundings, fluid medium temperature) |
| DC regular power supply, battery, solar panel, photovoltaic panel, car cigarette lighter. | |
| Customized functions (Optional) | Reverse Polarity protection, over voltage protection, over current protection, over-temperature protection, circuit protection, run-dry protection, PWM speed control, etc. |
| Application |
