Quick Details
-
Brand Name:
-
HEDY
-
Model Number:
-
HK-120W-12V
-
Output Frequency:
-
N/A
-
Output Current:
-
10A
-
Efficiency(Typ.):
-
83%
-
Input inrush Current (Typ.):
-
20A/115VAC 40/230VAC
-
Voltage Adj. Range:
-
11.4~13.2V
-
Voltage Tolerance:
-
±2.0%
-
Over Voltage:
-
13.2~16.2V
-
Over load:
-
110~200% rated output power
-
Current Range:
-
0~10A
-
Ripple & Noise (max.):
-
100mVp-p
-
Input frequency Range:
-
47~63HZ
-
Leakage Current:
-
<2mA / 240VAC
Quick Details
-
Input Voltage:
-
180-264vac
-
Output Voltage:
-
12V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HEDY
-
Model Number:
-
HK-120W-12V
-
Output Frequency:
-
N/A
-
Output Current:
-
10A
-
Efficiency(Typ.):
-
83%
-
Input inrush Current (Typ.):
-
20A/115VAC 40/230VAC
-
Voltage Adj. Range:
-
11.4~13.2V
-
Voltage Tolerance:
-
±2.0%
-
Over Voltage:
-
13.2~16.2V
-
Over load:
-
110~200% rated output power
-
Current Range:
-
0~10A
-
Ripple & Noise (max.):
-
100mVp-p
-
Input frequency Range:
-
47~63HZ
-
Leakage Current:
-
<2mA / 240VAC
Welcome
Product Description
| Model | HK-120W-3.3V | HK-120W-5V | HK-120W-12V | HK-120W-15V | HK-120W-24V | HK-120W-36V | |
| Output | DC Voltage | 3.3V | 5V | 12V | 15V | 24V | 36V |
| Rated Current | 36A | 24A | 10A | 8A | 5A | 3.5A | |
| Current Range | 0~36A | 0~24A | 0~10A | 0~8A | 0~5A | 0~3.5A | |
| Rated Power | 118.8W | 120W | 120W | 120W | 120W | 126W | |
| Ripple & Noise (max.) | 100mVp-p | 100mVp-p | 100mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | |
| Voltage Adj. Range | 3.14~3.63V | 4.75~5.5V | 11.4~13.2V | 14.3~16.5V | 22.8~26.4V | 34.2~39.6V | |
| Voltage Tolerance | ±2.0% | ±2.0% | ±2.0% | ±2.0% | ±1.0% | ±1.0% | |
| Line Regulation | ±1.0% | ±1.0% | ±1.0% | ±1.0% | ±0.5% | ±0.5% | |
| Load Regulation | ±5.0% | ±5.0% | ±5.0% | ±5.0% | ±5.0% | ±5.0% | |
| Setup,Rise time | 600ms,30ms at full load | ||||||
| Hold Up Time(Typ.) | 13ms at full load | ||||||
| Input | Voltage Range | 90~132VAC or 180~264VAC available(Standard configuration is 180-264vac) | |||||
| Frequency Range | 47~63HZ | ||||||
| Efficiency(Typ.) | 83% | 83% | 83% | 86% | 88% | 91% | |
| AC Current (Typ.) | 5A/115VAC 3A/230VAC | ||||||
| Inrush Current (Typ.) | 20A/115VAC 40A/230VAC | ||||||
| Leakage Current | <2mA / 240VAC | ||||||
| Protection | Over Load | 110~200% rated output power | |||||
| Protection type: Shut down O/P,recovers automatically | |||||||
| Over Current | 110~200% rated output current | ||||||
| Protection type: Shut down O/P,re-power on to recover | |||||||
| Short circuit | Protection type: Shut down O/P,recovers automatically after fault removed | ||||||
| Environment | Working Temperature | -20~+40°C | |||||
| Working Humidity | 20~90% RH Non-condensing | ||||||
| Storage temp.& humidity | -20~+85°C, 10~95%RH | ||||||
| Temp. coefficient | ±0.03%/°C (0~50°C) | ||||||
| Vibration | 10 ~ 500Hz, 3G 10min./1 cycle,60min.each along X,Y,Z axes | ||||||
| Safety & EMC | Safety Standards | UL60950-1 | |||||
| Withstand Voltage | I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG:0.5KVAC | ||||||
| Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25°C/ 70% RH | ||||||
| Others | MTBF | 10000hrs MIL-HDBK-217F (25°C) | |||||
| Dimension | 159*95*50 mm | ||||||
| Packing | |||||||
| Note | 1. All parameters NOT specially mentioned are measured at 220VAC input, rated load and 25°C of ambient temperature. | ||||||
| 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 10uf parallel capacitor. | |||||||
| 3. Tolerance: includes set up tolerance, line regulation and load regulation. | |||||||
| 4. Derating may be needed under low input voltages. | |||||||
