windshield wiper and horn, etc.
It can be widely u sed in pure electric vehicles and hybrid electri c vehicles.
The input voltage range is 400~750VDC DC input, single output 27.5VDC.
Contact us For product pricing, customization, or other inquiries:
Contact Us
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
GSEV027110A-B01
-
Output Frequency:
-
/
-
Size:
-
W207*D304*H121.7mm
-
Weight:
-
7Kg
-
Certificate:
-
CE
-
Input voltage range:
-
DC 400V~750V
-
Output voltage:
-
DC 27.5V±0.5V
-
Output Current range:
-
0~110A
-
full load efficiency:
-
≥94%
-
size (W*D*H):
-
207*304*121.7mm
-
weight:
-
7Kg
-
IP Grade:
-
IP67
-
working temperature:
-
-40℃~+75℃(derate over 65℃)
-
relative humidity:
-
≤95%, non-condensing
-
cooling method:
-
air cooling
Quick Details
-
Output Current:
-
0~110A
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Grasen
-
Model Number:
-
GSEV027110A-B01
-
Output Frequency:
-
/
-
Size:
-
W207*D304*H121.7mm
-
Weight:
-
7Kg
-
Certificate:
-
CE
-
Input voltage range:
-
DC 400V~750V
-
Output voltage:
-
DC 27.5V±0.5V
-
Output Current range:
-
0~110A
-
full load efficiency:
-
≥94%
-
size (W*D*H):
-
207*304*121.7mm
-
weight:
-
7Kg
-
IP Grade:
-
IP67
-
working temperature:
-
-40℃~+75℃(derate over 65℃)
-
relative humidity:
-
≤95%, non-condensing
-
cooling method:
-
air cooling
Products Description
windshield wiper and horn, etc.
It can be widely u sed in pure electric vehicles and hybrid electri c vehicles.
The input voltage range is 400~750VDC DC input, single output 27.5VDC.
Applications:
This converter is mainly used for electric buses, city trolleys, trams, subways, AGV, and light rail, as a DC power supply.
Protections:
The machine is equipped with single chip microcomputer, which supports input over-voltage protection, output over-current protection, output over-voltage protection, output short-circuit protection and over-temperature protection.
|
Model number
|
GSEV027110A-B01
|
|
|
|
|||
|
Power
|
3000W
|
|
|
|
|||
|
Input voltage range
|
DC 400V~750V
|
|
|
|
|||
|
Output voltage
|
DC 27.5V±0.5V
|
|
|
|
|||
|
Output current range
|
0~110A
|
|
|
|
|||
|
full load efficiency
|
≥94%
|
|
|
|
|||
|
size (W*D*H)
|
207*304*121.7mm
|
|
|
|
|||
|
weight
|
7kg
|
|
|
|
|||
|
IP Grade
|
IP67
|
|
|
|
|||
|
working temperature
|
-40℃~+75℃(derate over 65℃)
|
|
|
|
|||
|
relative humidity
|
≤95%, non-condensing
|
|
|
|
|||
|
cooling method
|
air cooling
|
|
|
|
|||
|
Protections
|
Input over-voltage/under-voltage protection, output over-voltage/under-voltage protection, output over-current protection, output
short-circuit protection, over-temperature protection
|
|
|
|
|||
