Quick Details
-
Place of Origin:
-
Henan, China
-
Classfication:
-
dental lab heating processing equipment
-
Application:
-
lab muffle furnace for zirconia sintering
-
style:
-
1700.C electric muffle furnace for ceramic
-
type:
-
high temperature sintering ceramic furnace
-
Max. temperature:
-
1700.C
-
working temperature:
-
1600.C continuous
-
Chamber size:
-
300*200*200mm
-
use:
-
electric furnace for ceramic sintering
-
usage:
-
1700C sintering furnace for porcelain
-
Voltage:
-
220V
Quick Details
-
Warranty:
-
1 year
-
Brand Name:
-
Xinkyo
-
Model Number:
-
SX2-9-17TP
-
Place of Origin:
-
Henan, China
-
Classfication:
-
dental lab heating processing equipment
-
Application:
-
lab muffle furnace for zirconia sintering
-
style:
-
1700.C electric muffle furnace for ceramic
-
type:
-
high temperature sintering ceramic furnace
-
Max. temperature:
-
1700.C
-
working temperature:
-
1600.C continuous
-
Chamber size:
-
300*200*200mm
-
use:
-
electric furnace for ceramic sintering
-
usage:
-
1700C sintering furnace for porcelain
-
Voltage:
-
220V
Product Description
Technology parameter
| Max.temperature | 1700C |
| Working temperature | 0-1600C |
| Furnace Chamber size(DWH)mm | 300*200*200 or as your requirement |
| Heat element | MoSi2 heater |
| voltage and frequency | 220v 50Hz/60Hz |
| Heating rate | 0-20C/min |
| Temperature accuracy | ±1°C |
| Thermocouple | B type |
| Adopt international advanced temperature controller, with 30-50 programmable PID self-tuning, automatic temperature rise, automatic temperature drop, no duty. | |
| The electric furnace adopts integrated circuit, module control, double circuit protection (partial temperature protection, ultra-high temperature protection, coupling protection, overcurrent protection, overpressure protection and other protection functions) to make the electric furnace work stable and reliable, safe. | |
| Adopt the most advanced light alumina ceramic fiber in the world, with excellent thermal insulation effect, light weight, high temperature resistance, cold and heat resistance, no crack, no crystallization, no slag, do not worry about pollution of the fired products. The energy saving effect is 60-80% of the old electric furnace. | |
| Furnace adopts the stepped assembly structure, integrating the mechanical law, effectively ensure the furnace in the heating process of uniform force, ensure that the heat is not easy to disperse, prolong the service life of the furnace. | |
| Sandard accessories | Crucible tongs 1pc, Thermal gloves 1 pair,User manual 1 pc,other small tools for assembly furnace |
| Other temperature options | 1200C,1400C,1700C,1800C |
| Furnace chamber standard size | 100*100*100mm,200*150*150mm,300*200*200mm,400*300*300mm or other OEM size |
| Waranty | One year |
