Quick Details
-
Tilting Angle(°):
-
110°
-
Power (kW):
-
10 kW
-
Compressed Air Pressure(MPa):
-
0.7 MPa
-
Brand Name:
-
XIHUA
-
Model Number:
-
XH-420
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1450*920*2050
-
Year:
-
2022
-
Weight (KG):
-
800 KG
-
Applicable Industries:
-
Plastic and rubber
-
Type:
-
Rubber Mixer
-
color:
-
orange
-
Mixing capacity:
-
1L
-
rotor speed:
-
40/31r/m
-
cylinder diameter of top peg:
-
80mm
-
package:
-
wooden case
-
power:
-
electricity
-
Certification:
-
CE ISO9001
-
Marketing Type:
-
New Product 2022
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Condition:
-
new, New
-
Mixing Capacity(L):
-
1 L
-
Tilting Angle(°):
-
110°
-
Power (kW):
-
10 kW
-
Compressed Air Pressure(MPa):
-
0.7 MPa
-
Brand Name:
-
XIHUA
-
Model Number:
-
XH-420
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1450*920*2050
-
Year:
-
2022
-
Weight (KG):
-
800 KG
-
Applicable Industries:
-
Plastic and rubber
-
Type:
-
Rubber Mixer
-
color:
-
orange
-
Mixing capacity:
-
1L
-
rotor speed:
-
40/31r/m
-
cylinder diameter of top peg:
-
80mm
-
package:
-
wooden case
-
power:
-
electricity
-
Certification:
-
CE ISO9001
-
Marketing Type:
-
New Product 2022
Certifications
Product Description
Product Application
|
Technical Parameters
|
|
|
||
|
Mixing Capacity
|
1L, 3L, 5L, 10L (can be customized)
|
|
||
|
Control mode
|
Key control, PLC control (optional)
|
|
||
|
Rotor speed(front/back)
|
40/31r/m(speed adjustable)
35/28 r/min (speed adjustable)
|
|
||
|
Cylinder diameter of top peg
|
80mm
|
|
||
|
Compressed air pressure
|
0.5~0.8MPa
|
|
||
|
Flip motor
|
0.75 kw
|
|
||
|
Heating mode
|
oil heating or electrical heating
|
|
||
|
Temperature
|
room tempe ~300°C
|
|
||
|
High temp oil pump
|
0.75KW-350°C wheelcoupled(lift:20m, flow:3/H)
|
|
||
|
Power of main motor
|
5.5 KW
|
|
||
|
Rotate speed of motor
|
1440rpm
|
|
||
|
Title angle of Mixing chamber
|
110°
|
|
||
|
Power
|
3Ø, AC380V, 20A
|
|
||
Our service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
* Engineers available to service machinery overseas.
Contact information
Packing & Delivery
|
Packaging
|
|
|
|
Size
|
(W)1550*(D)1020*(H)2150MM
|
|
|
Weight
|
850kg
|
|
|
Packaging Details
|
wooden box
|
|
