Quick Details
-
Brand Name:
-
Winston/OEM
-
Model Number:
-
SP-500-12 electrolysis power supply-10
-
Output Frequency:
-
47-63HZ
-
Output Current:
-
40A 36A 32A 20A 18A 10A
-
Certification:
-
CE,ROHS
-
Fuction:
-
PFC
-
model:
-
500w electrolysis power supply
Quick Details
-
Input Voltage:
-
88-264VAC 124-370VDC
-
Output Voltage:
-
24V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Winston/OEM
-
Model Number:
-
SP-500-12 electrolysis power supply-10
-
Output Frequency:
-
47-63HZ
-
Output Current:
-
40A 36A 32A 20A 18A 10A
-
Certification:
-
CE,ROHS
-
Fuction:
-
PFC
-
model:
-
500w electrolysis power supply
New Product 80V 1200W 72V Dc Output 70V 60V 5V60a 5V Rainproof 80A 200A Power Supply
Application
| AC input voltage range:88~264VAC 47~63Hz;124~370VDC | ||||||||||
| Input current:7A/115V 3.5A/230V | ||||||||||
| Power factor:0.95A/100~240VAC | ||||||||||
| AC inrush current:18A/115V 36A/230V | ||||||||||
| Leakage current:<3.5mA/240VAC | ||||||||||
| Overload protection:105%~135% Type:plusing hiccup shutdown Reset:auto recovery | ||||||||||
| High-temperature protection:RTH>=55CFan on,=<45CFan off>=70C Cut off output(5~15V)output shutdown | ||||||||||
| Temperature coefficient:±0.03%/C(0~50C) | ||||||||||
| Setup rise hold-up time:1.5s,50ms,20ms | ||||||||||
| Vibration:10~500Hz,2G 10min,/1cycle,Period for 60min,Each axes | ||||||||||
| Withstand voltage:Input and output internal:1.5KvAC,Input and enclosure:1.5KvAC,Output and enclosure:0.5KvAC | ||||||||||
| Isolation resistance:Input and output internal,input and enclosure,output and enclosure:500VDC/100MΩ | ||||||||||
| Working temperature and humidity:-10C~+60C(Refer to output derating curve),20%~90%RH | ||||||||||
| Store temperature and humidity:-20C~+85V, 10%~95%RH | ||||||||||
| Overall dimension:185*120*93mm | ||||||||||
| Weight:1.8Kgs | ||||||||||
| Safety standards:Meet UL1950requirement(Not apply for the mark) | ||||||||||
| EMC standards:CISPR22(EN55022),IEC1000-4,2,3,4,5,6,8,11 IEC1000-3-2 | ||||||||||
Technic data
| Index Type | SP-500-12 | SP-500-13.5 | SP-500-15 | SP-500-24 | SP-500-27 | SP-500-48 |
| DC Voltage | 12V | 13.5V | 15V | 24V | 27V | 48V |
| Voltage Tolerance | ±2% | ±2% | ±1% | ±1% | ±1% | ±1% |
| Rated Current | 40A | 36A | 32A | 20A | 18A | 10A |
| Current Range | 0-40A | 0-36A | 0-32A | 0-20A | 0-18A | 0-10A |
| Ripple&Noise(Max.) | 240mVp-p | 240mVp-p | 240mVp-p | 240mVp-p | 200mVp-p | 300mVp-p |
| Line Regulation | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
| Load Regulation | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
| Rated Power | 480W | 486W | 480W | 480W | 486W | 480W |
| Efficiency | 84% | 84% | 83% | 85.5% | 86.5% | 87% |
| Voltage Adjust Range | 10-13.2V | 12-15V | 13.5-18V | 20-26.4V | 24-30V | 41-56V |
