Quick Details
-
Output Power:
-
10KW
-
Input Voltage:
-
380V
-
Output Voltage:
-
380V
-
Output Current:
-
26.2A
-
Output Frequency:
-
50/60Hz
-
Output Type:
-
on grid
-
Inverter Efficiency:
-
98%
-
Application:
-
On-Grid Wind System
-
Display:
-
LCD Screen
-
Operation mode:
-
Continuous
-
Monitoring system:
-
RS485/RS232/WIFI/GPRS/Enternet
-
AC wiring mode:
-
Three phase four wire
-
Rated output power:
-
10KW
-
Power factor:
-
>0.99
-
Max. efficiency:
-
98%
-
Rated grid voltage(AC):
-
220V / 380V / 440V
-
Grid voltage range:
-
+-20%
-
Type:
-
DC/AC Inverters
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ENGELEC
-
Model Number:
-
EEPL-10KW-100KW
-
Output Power:
-
10KW
-
Input Voltage:
-
380V
-
Output Voltage:
-
380V
-
Output Current:
-
26.2A
-
Output Frequency:
-
50/60Hz
-
Output Type:
-
on grid
-
Inverter Efficiency:
-
98%
-
Application:
-
On-Grid Wind System
-
Display:
-
LCD Screen
-
Operation mode:
-
Continuous
-
Monitoring system:
-
RS485/RS232/WIFI/GPRS/Enternet
-
AC wiring mode:
-
Three phase four wire
-
Rated output power:
-
10KW
-
Power factor:
-
>0.99
-
Max. efficiency:
-
98%
-
Rated grid voltage(AC):
-
220V / 380V / 440V
-
Grid voltage range:
-
+-20%
-
Type:
-
DC/AC Inverters
| Type | EEPL-10K | EEPL-20K | EEPL-30K | EEPL-50K | EEPL-75K | EEPL-100K |
| Capacity | 10KVA | 20KVA | 30KVA | 50KVA | 75KVA | 100KVA |
| Circuit way | IGBT/PWM Delta Modulation Technique | |||||
| Ac Input | ||||||
| Input mode | Three phase four wire | |||||
| Voltage range | 380V±30% | |||||
| Frequency domain | 30-70Hz | |||||
| Ac Output | ||||||
| Rated Capacity | 10KVA | 20KVA | 30KVA | 30KVA | 75KVA | 100KVA |
| Output mode | Three phase four wire | |||||
| Output wave | Pure sine wave | |||||
| Output voltage | L-L:220V/ 380V/400V ; L-N: 127V/220V/231; | |||||
| Voltage accuracy | ±1% | |||||
| Output frequency | 50Hz/60HZ | |||||
| Output frequency | ±0.01% | |||||
| Output rated current | ||||||
| Overload Capacity | 110%,3 minutes, 200%,10 second | |||||
| 2%(0~100% load change) | ||||||
| THDV | THD<3%(nonlinear load) | |||||
| Display usage | ||||||
| Display Window | High Precision LCD touch screen display | |||||
| Voltmeters | Precision 0.1V | |||||
| Current meters | Precision 0.1A | |||||
| Frequency table | Precision 0.1Hz | |||||
| Power | Precision 0.1W | |||||
| Communication | RS485/RS232/WIFI/GPRS/Enternet(Optional) | |||||
| System | ||||||
| System efficiency | Normal mode: 90% | |||||
| Insulation resistance | DC> 500V 20MΩ | |||||
| Dielectric strength | (Input and output to the ground)1800Vdc,Leakage current is less than 3.5mA,1 minute without arc | |||||
| Level of protection | IP22 | |||||
| Mode of connection | Output Terminal block | |||||
| Heat-dissipating method | Forced fan refrigeration | |||||
| Operating temperature | -10℃~+50℃ | |||||
| Relative humidity | 0-90%(without condensation) | |||||
| Noise(dB) | <65Db | |||||
| Size (mm) | 500*950*1100 | 550*1050*1200 | 520*1160*1375 | 710*1410*1710 | 720*1510*1700 | 750*1500*1800 |
| Weight (kg) | 160 | 205 | 380 | 505 | 610 | 665 |
