Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
YUANDA
-
Model Number:
-
YD PLATE
-
OEM:
-
YES
-
Name:
-
Quartz glass disc
-
Purity:
-
99.99%
-
Operating Temperature:
-
1200℃
-
Soften Temperature:
-
1650℃
-
Melt Point:
-
1750-1850℃
-
Color:
-
Clear
-
Size:
-
base on customer's need
-
Advantage:
-
High temperature resistnat
-
Package:
-
foam and carton
Quick Details
-
Type:
-
Clear Quartz Plate
-
Application:
-
experiment, industry
-
Thickness:
-
1mm--100mm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
YUANDA
-
Model Number:
-
YD PLATE
-
OEM:
-
YES
-
Name:
-
Quartz glass disc
-
Purity:
-
99.99%
-
Operating Temperature:
-
1200℃
-
Soften Temperature:
-
1650℃
-
Melt Point:
-
1750-1850℃
-
Color:
-
Clear
-
Size:
-
base on customer's need
-
Advantage:
-
High temperature resistnat
-
Package:
-
foam and carton
PRODUCT DATA
QUARTZ PLATE
Our Advantages
PROCESS
GRINDING, LAPPING, & POLISHING
.
Attention for quartz plate
1. Do not operate in temperature beyond quartz maximum working temperature for long time. Otherwise, products will deform
crystallization or become softening.
2. Clean the quartz products before high temperature environment operation .
Firstly soak the products in 10% hydrofluoric acid, then wash it with high purity water or alcohol
Operator should wear thin gloves , direct touch with the quartz glass by hand is inhibited.
3. It is wise to extend the lifespan and thermal resistance of quartz products via continuous use within high temperature
environment. Otherwise, interval use shall shorten products lifespan.
4. Try to avoid touch with alkaline substances (such as water glass, asbestos, potassium and sodium compounds, etc.)when employing
quartz glass products in high temperature, which is made of acid material. Otherwise product anti- crystalline properties will be
greatly reduced.
1. Do not operate in temperature beyond quartz maximum working temperature for long time. Otherwise, products will deform
crystallization or become softening.
2. Clean the quartz products before high temperature environment operation .
Firstly soak the products in 10% hydrofluoric acid, then wash it with high purity water or alcohol
Operator should wear thin gloves , direct touch with the quartz glass by hand is inhibited.
3. It is wise to extend the lifespan and thermal resistance of quartz products via continuous use within high temperature
environment. Otherwise, interval use shall shorten products lifespan.
4. Try to avoid touch with alkaline substances (such as water glass, asbestos, potassium and sodium compounds, etc.)when employing
quartz glass products in high temperature, which is made of acid material. Otherwise product anti- crystalline properties will be
greatly reduced.
