Quick Details
-
Engine oil system capacity:
-
1.1L
-
Maximum Torque:
-
26.5N.m
-
Bore *stroke:
-
88*64mm
-
Volume:
-
389cm3
-
Compression Ratio:
-
8.0:1
-
Maximum Power Output:
-
13HP/9.6Kw
-
Dimensions:
-
515*450*490mm
-
Net Weight:
-
31kg
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Engine type:
-
1-cylinder 4-stroke
-
Fuel capacity:
-
6.5L
-
Engine oil system capacity:
-
1.1L
-
Maximum Torque:
-
26.5N.m
-
Bore *stroke:
-
88*64mm
-
Volume:
-
389cm3
-
Compression Ratio:
-
8.0:1
-
Maximum Power Output:
-
13HP/9.6Kw
-
Dimensions:
-
515*450*490mm
-
Net Weight:
-
31kg
| Model | LB188F | LB190F |
| Engine type | sinlge cylinder ,4-stroke ,OHV | sinlge cylinder ,4-stroke ,OHV |
| Bore*stroke | 88*64(mm) | 90*66(mm) |
| Volume | 389cm³ | 407cm³ |
| Compression ratio | 8.0:1 | 8.0:1 |
| (13.0HP)9.6kw | (15.0HP)11kw | |
| (11.7HP)8.6kw | (13HP)9.6kw | |
| Maximum torque | 26.5N/m | 28N/m |
| Ignition system | ||
| Starting system | Recoil/electric | Recoil/electric |
| 1.1 L | 1.1 L | |
| Fuel capacity | 6.5 L | 6.5 L |
| Min.fuel consumption | 325g/kw/h | 325g/kw/h |
| Power output type | crankshaft 1:1 | crankshaft 1:1 |
| Left | Left | |
| Air cleaner | ||
| Dimensions | 495*420*505mm | 495*420*505mm |
| Net weight | 31kgs | 31kgs |
