Quick Details
-
Brand Name:
-
YPS
-
Model Number:
-
YPS-400
-
Product name:
-
Double Loop Wire Binding Machine
-
Machine type:
-
Manual
-
Wire Specifications:
-
Diameter: 1/4"-11/4"
-
Pitch:
-
3:1 & 2:1
-
Max Paper Width:
-
620mm
-
Working speed:
-
900-1200 cycles/hour
-
After Warranty Service:
-
Video technical support
-
Machine Net Weight:
-
360kg
-
Certification:
-
ISO 9001
Quick Details
-
Type:
-
Wire Binding Machine
-
Power:
-
Electricity
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
YPS
-
Model Number:
-
YPS-400
-
Product name:
-
Double Loop Wire Binding Machine
-
Machine type:
-
Manual
-
Wire Specifications:
-
Diameter: 1/4"-11/4"
-
Pitch:
-
3:1 & 2:1
-
Max Paper Width:
-
620mm
-
Working speed:
-
900-1200 cycles/hour
-
After Warranty Service:
-
Video technical support
-
Machine Net Weight:
-
360kg
-
Certification:
-
ISO 9001
| Wire Specifications | Diameter:1/4"---1-1/2" ; Pitch :3:1 & 2:1 |
| Handing of Double Wire | |
| Max.Binding Width | 360mm |
| Min Binding Width | 70mm |
| Working Speed | 1300-1600 cycles/hour |
| Size of Workable | 1000x700mm |
| Power Supply | 220v/ 1ph/ 50hz/60Hz |
| Air Pressure | 6-8bar |
| Machine Dimension | 1600x1080x1300mm |
| Dimensions of Pay- Off Unit | 800x450x1100mm |
| Dimensions of Conveyor | 1700x500x880mm |
| Net Weigth of Machine | 300kgs |
