Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
A&ELAB
-
Model Number:
-
EXPLORER 5000
-
Focal Length:
-
adjustable
-
Analytical Method:
-
Energy dispersive X ray fluorescence analytical Method
-
Elements Measuring range:
-
Atomic number from 12 to 92
-
Simultaneous detector elements:
-
Simultaneous analysis 40 elements
-
Microcomputer system:
-
Customized system
-
The content range:
-
Ppm~99.99%
-
The detection time:
-
1-60 seconds (a second report results)
-
A built-in system:
-
GPS, WIFI, Wireless
-
Power Supply:
-
Rechargeable lithium battery
-
Detection Objective:
-
Solid, liquid, powder
-
Detector:
-
SDD detector or Fast-SDD detector (optional)
Quick Details
-
Warranty:
-
1 YEAR
-
Size:
-
25*10*35 cm
-
Weight:
-
2
-
Place of Origin:
-
China
-
Brand Name:
-
A&ELAB
-
Model Number:
-
EXPLORER 5000
-
Focal Length:
-
adjustable
-
Analytical Method:
-
Energy dispersive X ray fluorescence analytical Method
-
Elements Measuring range:
-
Atomic number from 12 to 92
-
Simultaneous detector elements:
-
Simultaneous analysis 40 elements
-
Microcomputer system:
-
Customized system
-
The content range:
-
Ppm~99.99%
-
The detection time:
-
1-60 seconds (a second report results)
-
A built-in system:
-
GPS, WIFI, Wireless
-
Power Supply:
-
Rechargeable lithium battery
-
Detection Objective:
-
Solid, liquid, powder
-
Detector:
-
SDD detector or Fast-SDD detector (optional)
Product Description
Features & Specification
Technical Specifications:
|
Model
|
EXPLORER 7000
|
|
Analytical Method
|
Energy dispersive X ray fluorescence analytical Method
|
|
Elements Measuring range
|
Atomic number from 12 to 92 [elements from magnesium(Mg) to uranium (U)] can be measured
|
|
Simultaneous detector elements
|
Simultaneous analysis 40 elements
|
|
Microcomputer system
|
Customized system; CPU: 1G ; system memory: 1G;extended stored maximum support 32G ; standard 4G tor mass storage data
|
|
The content range
|
Ppm~99.99%
|
|
The detection time
|
1-60 seconds (a second report results)
|
|
A built-in system
|
GPS, WIFI, Wireless
|
|
Power Supply
|
Rechargeable lithium battery, standard is 9000mAh, sustainable work up to 12 hours; optional is 27000mAh super battery with wide
voltage 110V一220V universal adapter for recharging power supply
|
|
Detection Objective
|
Solid, liquid, powder
|
|
Detector
|
SDD detector or Fast-SDD detector (optional)
|
|
Detector resolution
|
Minimum can reach 128ev
|
|
The excitation source
|
50KV/200uA- silver target end window integrated miniature X ray tube and high voltage power supply
|
|
Collimator and filter
|
Collimator diameter are 4.0mm and 2.0mm, 6 kinds of filters with automatic switching functions
|
|
Video system
|
500W pixel high resolution camera
|
|
Display screen
|
Brand new 5 inch transflective LCD touch screen, the resolution is 1080x720
|
|
Detection limit
|
The minimum detection limits at 1-500ppm
|
|
Safety
|
Multiple safety protection, no test, no radiation, radiation levels at work are far below the international standards, and has no
sample telemetry, automatic shut X light tube function. Standard radiation shields, thickened wall alloy test instrument
|
|
Specialty
|
Ore special edition analysis software, using intelligent one key test
|
|
Convenience of application
|
Key intelligent matching the best curve that no need to select curve
|
|
Data transmission
|
Digital multi-channel technology, SPI data transmission, quick analysis, the high count rate; waterproof mini USB, and can be
connected with a desktop computer
|
|
Operating ambient humidity
|
≤90%
|
|
Operating environmental temperature
|
-20°C-+50°C
|
|
Instrument dimension
|
244mm (Length) x 90mm (Width) x 330m (Height)
|
|
Instrument weight
|
1.7KG
|
|
Intelligent warming signals lndicator system
|
Green light means power on, red flushing means testing and yellow flushing means the problems
|
|
Accessories
|
Three-military-protection-box is compression, waterproof and shock absorption. Universal charger and car charger, 4G SD memory
card and card reader
Two Lithium battery and charger, PDA accessories, radiation shield. Optional accessories: the large battery, seat type test
support, Wireless printer, mil, manual pressure machine, and other options can to chosen…
|
