Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
YESENMED
-
Model Number:
-
YSTE-V5000
-
Focal Length:
-
4nm
-
Wavelength Range:
-
325-1000nm, 325-1000nm
-
Model:
-
YSTE-V5000
-
Optical System:
-
Single Beam,Grating 1200lines/mm
-
Spectral Bandwidth:
-
4nm
-
Wavelength Accuracy:
-
±2nm
-
Wavelength Repeatability:
-
1nm
-
Photometric Accuracy:
-
±0.5%T
-
Photometric Repeatability:
-
0.3%T
-
Photometric Mode:
-
T, A, C, F
-
Stray Light:
-
≤0.2%T
Quick Details
-
Warranty:
-
1 years
-
Size:
-
57*45*33
-
Weight:
-
9
-
Place of Origin:
-
China
-
Brand Name:
-
YESENMED
-
Model Number:
-
YSTE-V5000
-
Focal Length:
-
4nm
-
Wavelength Range:
-
325-1000nm, 325-1000nm
-
Model:
-
YSTE-V5000
-
Optical System:
-
Single Beam,Grating 1200lines/mm
-
Spectral Bandwidth:
-
4nm
-
Wavelength Accuracy:
-
±2nm
-
Wavelength Repeatability:
-
1nm
-
Photometric Accuracy:
-
±0.5%T
-
Photometric Repeatability:
-
0.3%T
-
Photometric Mode:
-
T, A, C, F
-
Stray Light:
-
≤0.2%T
Product Description
Specification
|
Model
|
YSTE-V5000
|
|
Optical System
|
Single Beam,Grating 1200lines/mm
|
|
Wavelength Range
|
325-1000nm
|
|
Spectral Bandwidth
|
4nm
|
|
Wavelength Accuracy
|
±2nm
|
|
Wavelength Repeatability
|
1nm
|
|
Photometric Accuracy
|
±0.5%T
|
|
Photometric Repeatability
|
0.3%T
|
|
Photometric Mode
|
T, A, C, F
|
|
Stray Light
|
≤0.2%T
|
|
Stability
|
± 0.002A/h @ 500nm
|
|
Display
|
LCD
|
|
Detector
|
Silicon Photodiode
|
|
Output
|
USB Port & Parallel Port(Printer)
|
|
Light Source
|
Tungsten Halogen Lamp
|
|
Power Requirements
|
AC 85~250V
|
|
Dimension
|
420*280*180mm
|
|
Weight
|
8kg
|
