DC540V-1.5KW built-in fan driver
-
Transport Package:
-
carton
-
Trademark:
-
sp
-
Origin:
-
CHINA
-
Output:
-
100pcs/day
-
Export Port:
-
hangzhou
-
Payment:
-
T/T
- Product Details
- {{item.text}}
Quick Details
-
Model NO:
-
DC540V-1.5KW
Product category:
Industrial Variable Frequency Controller - Industrial Fan Drive Controller
1、 Technical parameters
1. Rated working voltage: 150Vdc~650Vdc.
2. Rated input power: 1350W.
3. Working environment temperature: -25 ℃~65 ℃.
4. Protection method: Fill the driver cavity with glue.
5. Design pollution level: Level IV.
2、 Function Introduction
1. Power supply overvoltage protection, motor phase line overcurrent protection, power component over temperature protection, motor phase loss protection, locked rotor and other fault protection functions.
2. Equipped with heat dissipation fins, directly installed at the rear of the fan motor.
3. Equipped with serial communication control function and fault feedback output function.
3、 Product features
1. A corner observer based on model reconstruction, SVPWM sine wave 180 ° control.
2. No position sensor.
3. Use UART to set the output speed.
4. Meet 3C and UL certification requirements.
4、 Typical applications
Commercial air conditioning fan drive, can also be used for other fan drives
