Quick Details
-
Panel Size:
-
576MM X 576MM AND 960MM X 960MM
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
LM-P3
-
Tube Chip Color:
-
FULL COLOR
-
LED Chips:
-
Nationstar
-
Brightness:
-
More than 7000cd/sqm
-
Pixel density:
-
10000 pixels/sq.m.
-
Refresh frequency:
-
More than 3840HZ
-
Power supply:
-
Meanwell
-
Waterproof:
-
IP65
-
Working Temperature:
-
-45 degree - +65 degree
-
Horizontal/Vertical Viewing angle:
-
160 degree/120 degree
-
Input voltage:
-
AC110~240 V
-
Pixel Pitch:
-
PIXEL PITCH 3MM
Quick Details
-
Application:
-
Outdoor And Indoor
-
Brand Name:
-
LEEMAN LED DISPLAY
-
Color:
-
SMD RGB Full color
-
Panel Size:
-
576MM X 576MM AND 960MM X 960MM
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
LM-P3
-
Tube Chip Color:
-
FULL COLOR
-
LED Chips:
-
Nationstar
-
Brightness:
-
More than 7000cd/sqm
-
Pixel density:
-
10000 pixels/sq.m.
-
Refresh frequency:
-
More than 3840HZ
-
Power supply:
-
Meanwell
-
Waterproof:
-
IP65
-
Working Temperature:
-
-45 degree - +65 degree
-
Horizontal/Vertical Viewing angle:
-
160 degree/120 degree
-
Input voltage:
-
AC110~240 V
-
Pixel Pitch:
-
PIXEL PITCH 3MM
| S/N | Item | Technical Parameters | |||
| LED Parameters | |||||
| 1 | Item Name | LED Chip Brand | Brightness | Wave Length | H/V Visual Angle |
| 2 | Red LED | Nationstar | 120-140mcd | 620-625nm | 160º/120º |
| 3 | Green LED | Nationstar | 360-435mcd | 520-525nm | 160º/120º |
| 4 | Blue LED | Nationstar | 80-100mcd | 470-475nm | 160º/120º |
| Module Specification | |||||
| 1 | Pixel Pitch | 3mm | |||
| 2 | Pixel Configuration | SMD 1415 | |||
| 3 | Module Resolution | 64 x 64 pixels | |||
| 4 | Module Pixles | 4096 pixels | |||
| 5 | Module Size | 192mm X 192mm | |||
| Cabinet Specification | |||||
| 1 | Cabinet Size(W X H X D) | 576mm x 576mm x 80mm | |||
| 2 | Cabinet Resolution(dot) | 192 x 192 pixels | |||
| 3 | Module Quanity (pcs) | 9pcs | |||
| 4 | Cabinet Pixels | 36864 pixels | |||
| 5 | Pixel Density | 111111 pixels/m2 | |||
| 6 | Cabinet Materials | Die Casting Aluminum Cabinet for rental purpose | |||
| 7 | Cabinet Weight | 8.5kg per cabinet | |||
| 8 | Packaging | Fly case | |||
| 9 | Fly Case Size | 77CM*63CM*80CM ( one case for six cabinets ) | |||
| Whole Screen Specification | |||||
| 1 | Screen Brightness | ≥7000cd/m2 | |||
| 2 | Driving Method | 1/16 scan | |||
| 3 | Best Viewing Distance | 3m - 30m | |||
| 4 | Max. Power Consumption | 600W/m2 | |||
| 5 | Average Power Consumption | 300W/m2 | |||
| 6 | Gray Level | 8bits input, 4096 levels(212) | |||
| 7 | Display Color | 16M | |||
| 8 | Frame Frequency | ≥60Hz | |||
| 9 | Refresh Frequency | ≥3840Hz | |||
| 10 | Uninterrupted Working Hours | ≥72 hours | |||
| 11 | Screen Life-span | ≥100,000 hours | |||
| 12 | MTBF | ≥5,000 hours | |||
| 13 | Discrete Blind Spot Rate | <1/10000 | |||
| 14 | Continuous Blind Spot Rate | None | |||
| 15 | Blind Spot Rate | <1/10000 | |||
| 16 | Protective Scale | For indoor use only | |||
| 17 | Screen Plainness | <±1mm | |||
| 18 | Power Supply Mode | AC220±10% 50Hz / AC110±10% 60Hz | |||
| 19 | Environment Temperature & Humidity | Temperature:-30 Celsius~+60 Celsius | |||
| Humidity:10%~90% RH | |||||
| 20 | Control Mode | Synchronous display with control PC by DVI | |||
| 21 | Control System | Linsn, Novastar, Colorlight, Huidu card or as you required | |||
| 22 | Display Content | Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc. | |||
| 23 | Interface | Standard Ethernet | |||
| 24 | Transmission Distance | Multi mode fiber <500m, single mode fiber <30km,internet cable <100m | |||
