Quick Details
-
Brand Name:
-
Cinow
-
Model Number:
-
LA210A,LA212A,LA215A,LA118A,LA121A,LA224A
-
Dimension (L x W x H):
-
62x24x30
-
Item:
-
Active Line Array
-
Channels:
-
Dual 6" 8" 10" 12" 15"
-
DSP:
-
Each speaker has integrated self-R&D amp module
-
Outdoor:
-
Waterproof polyurea paint
-
Width voltage:
-
AC 90~264V, DC 100-240V
-
Hi Driver Angle:
-
horizontal 110 Vertical 15
-
Sensitivity:
-
103dB
-
product name:
-
water-proof active line array with dsp inside
Quick Details
-
Power:
-
450w,600w,700w,800w, 450W,600W,700W,800W
-
Frequency Range (Hz):
-
50~20KHz
-
Place of Origin:
-
China (Mainland)
-
Brand Name:
-
Cinow
-
Model Number:
-
LA210A,LA212A,LA215A,LA118A,LA121A,LA224A
-
Dimension (L x W x H):
-
62x24x30
-
Item:
-
Active Line Array
-
Channels:
-
Dual 6" 8" 10" 12" 15"
-
DSP:
-
Each speaker has integrated self-R&D amp module
-
Outdoor:
-
Waterproof polyurea paint
-
Width voltage:
-
AC 90~264V, DC 100-240V
-
Hi Driver Angle:
-
horizontal 110 Vertical 15
-
Sensitivity:
-
103dB
-
product name:
-
water-proof active line array with dsp inside
Products Description
|
Item
|
Dual8"
|
Dual10"
|
Dual12"
|
Dual15"
|
|
Driver
|
2*8"LF+2*1"HF
|
2*10"LF+2*1.8"HF
|
2*12"LF+2*1.8"HF
|
2*15"LF+2*1.8"HF
|
|
DC-Impedance
|
12.8Ohm
|
12.8Ohm
|
12.8Ohm
|
12.8Ohm
|
|
Frequency Response(Hz/-6dB)
|
80~22kHz
|
70~22KHz
|
60~22KHz
|
50~20KHz
|
|
Power Consumption(W)
|
450W
|
600W
|
700W
|
800W
|
|
Peak Power(W)
|
1800W
|
2400W
|
2800W
|
3200W
|
|
Sensitivity(dB/m.w)
|
100dB
|
102dB
|
103dB
|
103dB
|
|
Max SPL(dB)
|
133-145dB
|
135-147dB
|
137-149dB
|
140-152dB
|
|
Dispersion(H°xV°)
|
110º horizontal,15º vertical
|
110º horizontal,15º vertical
|
110º horizontal,15º vertical
|
110º horizontal,15º vertical
|
|
Protective Grille
|
Black perforated steel
|
Black perforated steel
|
Black perforated steel
|
Black perforated steel
|
|
Net Weight(Kg)
|
18
|
26
|
32
|
40
|
|
Product Size(cm)
|
62x24x30
|
72x29x35
|
82x34x40
|
96x42x47
|
