Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
EVERSUN
-
Voltage:
-
220V/380V/415V or as per order
-
Dimension(L*W*H):
-
According to specific model
-
Weight (KG):
-
20 kg
-
Product name:
-
automatic grain powder granule pneumatic vacuum feeder conveyor
-
Function:
-
Conveying system
-
Customized:
-
Acceptable
-
Product Keywords:
-
vacuum conveyor for calcium nitrate
-
Application:
-
Conveying
-
Usage:
-
Material Transimission
-
Feature:
-
High Efficiency
-
Production time:
-
7 ~15 days
-
After-sales Service Provided:
-
Available
Quick Details
-
Power:
-
1.5-11kw
-
Warranty:
-
2 years
-
Width or Diameter:
-
300mm
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
EVERSUN
-
Voltage:
-
220V/380V/415V or as per order
-
Dimension(L*W*H):
-
According to specific model
-
Weight (KG):
-
20 kg
-
Product name:
-
automatic grain powder granule pneumatic vacuum feeder conveyor
-
Function:
-
Conveying system
-
Customized:
-
Acceptable
-
Product Keywords:
-
vacuum conveyor for calcium nitrate
-
Application:
-
Conveying
-
Usage:
-
Material Transimission
-
Feature:
-
High Efficiency
-
Production time:
-
7 ~15 days
-
After-sales Service Provided:
-
Available
Product Description
Features & Benefits
- GMP Standard Qualified
- High efficiency and safe conveying
- Convenient Installation and simple operation
- Dust-free working space
- Electriv Vacuum Conveyor
The electric vacuum conveyor is driven by electric motor, which has low vacuum energy consumption, no energy conversion, high efficiency and wide practical range.
| Electric Vacuum Conveyor | ||||
| Model | Delivey(kg/h) | Warehouse volume(L) | Operating pressure(Mpa) | Motor power(kW) |
| ZKJ-1 | 200-400 | 8 | 0.4-0.6 | 1.5 |
| ZKJ-2 | 400-600 | 8 | 0.4-0.6 | 2.2 |
| ZKJ-3 | 600-1200 | 12 | 0.4-0.6 | 3 |
| ZKJ-4 | 1200-2500 | 42 | 0.4-0.6 | 5.5(Single pole) |
| ZKJ-6 | 1500-3200 | 42 | 0.4-0.6 | 5.5 (Single pole) |
| ZKJ-7 | 2500-6000 | 60 | 0.4-0.6 | 7.5 |
| ZKJ-10-6 | About 6000(when transporting distance of 10m) | 120 | 0.4-0.6 | 7.5(Roots Fan) |
| ZKJ-20-5 | About 5000(when transporting distance of 10m) | 280 | 0.4-0.6 | 11 (Roots Fan) |
- Pnuematic Vacuum Conveyor
| Pnuematic Vacuum Conveyor | ||||
| Model | Delivey(kg/h) | Warehouse volume(L) | Operating pressure(Mpa) | Compressed air consumption(N/min) |
| QVC-1 | 50-300 | 1.1 | 0.4-0.6 | 180 |
| QVC-2 | 100-700 | 6.0 | 0.4-0.6 | 360 |
| QVC-3 | 300-1500 | 12.0 | 0.4-0.6 | 720 |
| QVC-4 | 600-3000 | 42 | 0.4-0.6 | 1440 |
